Microchip’s Digital-to-Analog Converters (DACs) meet the low-power needs of a myriad of precision-controlled conversion applications. Our DAC portfolio supports 8-bit, 10-bit and 12-bit resolution with one to four channels. Our unique, integrated non-volatile memory option allows the DAC’s configuration to be saved at power down reducing microcontroller overhead and simplify the system design. Several DAC devices offer high-precision control at 1 LSb of Integral Nonlinearity (INL) improving overall static and dynamic performance. Small form factor SOT-23 and DFN (2X2) packages support space-constrained designs.
Voltage References
Looking for stable voltage references for your data conversion system to help improve accuracy and reduce error? Check out our voltage reference products.
Analog-to-Digital Converters (ADCs)
Looking for a complete solution for your data conversion system? Explore our wide selection of ADC products.
View All Parametrics
| Product | Resolution (Bits) | DACs per Package | Interface | Vref | DNL (LSB) | Output Settling Time (µs) | Typical Operating Current (µA) | Typical Standby Current (µA) | Temperature Range(° C) | Automotive Recommended | Status | Packages | 5K Pricing |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MCP47CMB01 | 8 | 1 | I²C | Int,VDD,Ext | 0.1 | 16 | 400 | 0 | -40 to 125 | No | In Production | 10/DFN, 10/MSOP, 16/QFN | $0.64 |
| MCP47CMB02 | 8 | 2 | I²C | Int,VDD,Ext | 0.1 | 16 | 500 | 0 | -40 to 125 | No | In Production | 10/DFN, 10/MSOP, 16/QFN | $0.99 |
| MCP47CMB11 | 10 | 1 | I²C | Int,VDD,Ext | 0.25 | 16 | 400 | 0 | -40 to 125 | No | In Production | 10/DFN, 10/MSOP, 16/QFN | $0.84 |
| MCP47CMB12 | 10 | 2 | I²C | Int,VDD,Ext | 0.25 | 16 | 500 | 0 | -40 to 125 | No | In Production | 10/DFN, 10/MSOP, 16/QFN | $1.38 |
| MCP47CMB21 | 12 | 1 | I²C | Int,VDD,Ext | 1 | 16 | 400 | 0 | -40 to 125 | No | In Production | 10/DFN, 10/MSOP, 16/QFN | $1.18 |
| MCP47CMB22 | 12 | 2 | I²C | Int,VDD,Ext | 1 | 16 | 500 | 0 | -40 to 125 | No | In Production | 10/DFN, 10/MSOP, 16/QFN | $1.92 |
| MCP47CVB01 | 8 | 1 | I²C | Int,VDD,Ext | 0.1 | 16 | 400 | 0 | -40 to 125 | No | In Production | 10/DFN, 10/MSOP, 16/QFN | $0.53 |
| MCP47CVB02 | 8 | 2 | I²C | Int,VDD,Ext | 0.1 | 16 | 500 | 0 | -40 to 125 | No | In Production | 10/DFN, 10/MSOP, 16/QFN | $0.88 |
| MCP47CVB11 | 10 | 1 | I²C | Int,VDD,Ext | 0.25 | 16 | 400 | 0 | -40 to 125 | No | In Production | 10/DFN, 10/MSOP, 16/QFN | $0.73 |
| MCP47CVB12 | 10 | 2 | I²C | Int,VDD,Ext | 0.25 | 16 | 500 | 0 | -40 to 125 | No | In Production | 10/DFN, 10/MSOP, 16/QFN | $1.20 |
| MCP47CVB21 | 12 | 1 | I²C | Int,VDD,Ext | 1 | 16 | 400 | 0 | -40 to 125 | No | In Production | 10/DFN, 10/MSOP, 16/QFN | $1.07 |
| MCP47CVB22 | 12 | 2 | I²C | Int,VDD,Ext | 1 | 16 | 500 | 0 | -40 to 125 | No | In Production | 10/DFN, 10/MSOP, 16/QFN | $1.76 |
| MCP47FEB04 | 8 | 4 | I²C | Int,VDD,Ext | ±0.25 | 6 | 130 | 0.65 | -40 to 125 | No | In Production | Please call for package information | Call for pricing |
| MCP47FEB08 | 8 | 8 | I²C | Int,VDD,Ext | ±0.25 | 6 | 130 | 0.65 | -40 to 125 | No | In Production | 20/QFN, 20/TSSOP | $2.49 |
| MCP47FEB14 | 10 | 4 | I²C | Int,VDD,Ext | ±0.5 | 6 | 130 | 0.65 | -40 to 125 | No | In Production | Please call for package information | Call for pricing |
| MCP47FEB18 | 10 | 8 | I²C | Int,VDD,Ext | ±0.5 | 6 | 130 | 0.65 | -40 to 125 | No | Samples Available | 20/QFN, 20/TSSOP | $4.07 |
| MCP47FEB24 | 12 | 4 | I²C | Int,VDD,Ext | ±1.0 | 6 | 130 | 0.65 | -40 to 125 | No | In Production | Please call for package information | Call for pricing |
| MCP47FEB28 | 12 | 8 | I²C | Int,VDD,Ext | ±1.0 | 6 | 130 | 0.65 | -40 to 125 | No | Samples Available | 20/QFN, 20/TSSOP | $6.65 |
| MCP47FVB04 | 8 | 4 | I²C | Int,VDD,Ext | ±0.25 | 6 | 130 | 0.65 | -40 to 125 | No | Future Product | Please call for package information | Call for pricing |
| MCP47FVB08 | 8 | 8 | I²C | Int,VDD,Ext | ±0.25 | 6 | 130 | 0.65 | -40 to 125 | No | Samples Available | 20/QFN, 20/TSSOP | $2.47 |
| MCP47FVB14 | 10 | 4 | I²C | Int,VDD,Ext | ±0.5 | 6 | 130 | 0.65 | -40 to 125 | No | In Production | Please call for package information | Call for pricing |
| MCP47FVB18 | 10 | 8 | I²C | Int,VDD,Ext | ±0.5 | 6 | 130 | 0.65 | -40 to 125 | No | Samples Available | 20/QFN, 20/TSSOP | $4.04 |
| MCP47FVB24 | 12 | 4 | I²C | Int,VDD,Ext | ±1.0 | 6 | 130 | 0.65 | -40 to 125 | No | In Production | Please call for package information | Call for pricing |
| MCP47FVB28 | 12 | 8 | I²C | Int,VDD,Ext | ±1.0 | 6 | 130 | 0.65 | -40 to 125 | No | Samples Available | 20/QFN, 20/TSSOP | $6.63 |
| MCP48CMB01 | 8 | 1 | SPI | Int,VDD,Ext | 0.1 | 16 | 160 | 0 | -40 to 125 | No | In Production | 10/DFN, 10/MSOP, 16/QFN | $0.64 |
| MCP48CMB02 | 8 | 2 | SPI | Int,VDD,Ext | 0.1 | 16 | 280 | 0 | -40 to 125 | No | In Production | 10/DFN, 10/MSOP, 16/QFN | $0.99 |
| MCP48CMB11 | 10 | 1 | SPI | Int,VDD,Ext | 0.25 | 16 | 160 | 0 | -40 to 125 | No | In Production | 10/DFN, 10/MSOP, 16/QFN | $0.84 |
| MCP48CMB12 | 10 | 2 | SPI | Int,VDD,Ext | 0.25 | 16 | 280 | 0 | -40 to 125 | No | In Production | 10/DFN, 10/MSOP, 16/QFN | $1.38 |
| MCP48CMB21 | 12 | 1 | SPI | Int,VDD,Ext | 1 | 16 | 160 | 0 | -40 to 125 | No | In Production | 10/DFN, 10/MSOP, 16/QFN | $1.18 |
| MCP48CMB22 | 12 | 2 | SPI | Int,VDD,Ext | 1 | 16 | 280 | 0 | -40 to 125 | No | In Production | 10/DFN, 10/MSOP, 16/QFN | $1.92 |
| MCP48CVB01 | 8 | 1 | SPI | Int,VDD,Ext | 0.1 | 16 | 160 | 0 | -40 to 125 | No | In Production | 10/DFN, 10/MSOP, 16/QFN | $0.53 |
| MCP48CVB02 | 8 | 2 | SPI | Int,VDD,Ext | 0.1 | 16 | 280 | 0 | -40 to 125 | No | In Production | 10/DFN, 10/MSOP, 16/QFN | $0.88 |
| MCP48CVB11 | 10 | 1 | SPI | Int,VDD,Ext | 0.25 | 16 | 160 | 0 | -40 to 125 | No | In Production | 10/DFN, 10/MSOP, 16/QFN | $0.73 |
| MCP48CVB12 | 10 | 2 | SPI | Int,VDD,Ext | 0.25 | 16 | 280 | 0 | -40 to 125 | No | In Production | 10/DFN, 10/MSOP, 16/QFN | $1.20 |
| MCP48CVB21 | 12 | 1 | SPI | Int,VDD,Ext | 1 | 6 | 160 | 0 | -40 to 125 | No | In Production | 10/DFN, 10/MSOP, 16/QFN | $1.07 |
| MCP48CVB22 | 12 | 2 | SPI | Int,VDD,Ext | 1 | 16 | 280 | 0 | -40 to 125 | No | In Production | 10/DFN, 10/MSOP, 16/QFN | $1.76 |
| MCP48FEB04 | 8 | 4 | SPI | Int,VDD,Ext | ±0.25 | 7.8 | 130 | 0.65 | -40 to 125 | No | In Production | Please call for package information | Call for pricing |
| MCP48FEB08 | 8 | 8 | SPI | Int,VDD,Ext | ±0.25 | 7.8 | 130 | 0.65 | -40 to 125 | No | Samples Available | 20/QFN, 20/TSSOP | $2.49 |
| MCP48FEB14 | 10 | 4 | SPI | Int,VDD,Ext | ±0.5 | 7.8 | 130 | 0.65 | -40 to 125 | No | In Production | Please call for package information | Call for pricing |
| MCP48FEB18 | 10 | 8 | SPI | Int,VDD,Ext | ±0.5 | 7.8 | 130 | 0.65 | -40 to 125 | No | Samples Available | 20/QFN, 20/TSSOP | $4.07 |
| MCP48FEB24 | 12 | 4 | SPI | Int,VDD,Ext | ±1.0 | 7.8 | 130 | 0.65 | -40 to 125 | No | In Production | Please call for package information | Call for pricing |
| MCP48FEB28 | 12 | 8 | SPI | Int,VDD,Ext | ±1.0 | 7.8 | 130 | 0.65 | -40 to 125 | No | Samples Available | 20/QFN, 20/TSSOP | $6.65 |
| MCP48FVB04 | 8 | 4 | SPI | Int,VDD,Ext | ±0.25 | 7.8 | 130 | 0.65 | -40 to 125 | No | In Production | Please call for package information | Call for pricing |
| MCP48FVB08 | 8 | 8 | SPI | Int,VDD,Ext | ±0.25 | 7.8 | 130 | 0.65 | -40 to 125 | No | Samples Available | 20/QFN, 20/TSSOP | $2.47 |
| MCP48FVB14 | 10 | 4 | SPI | Int,VDD,Ext | ±0.5 | 7.8 | 130 | 0.65 | -40 to 125 | No | In Production | Please call for package information | Call for pricing |
| MCP48FVB18 | 10 | 8 | SPI | Int,VDD,Ext | ±0.5 | 7.8 | 130 | 0.65 | -40 to 125 | No | Samples Available | 20/QFN, 20/TSSOP | $4.04 |
| MCP48FVB24 | 12 | 4 | SPI | Int,VDD,Ext | ±1.0 | 16 | 130 | 0.65 | -40 to 125 | No | In Production | Please call for package information | Call for pricing |
| MCP48FVB28 | 12 | 8 | SPI | Int,VDD,Ext | ±1.0 | 16 | 130 | 0.65 | -40 to 125 | No | Samples Available | 20/QFN, 20/TSSOP | $6.63 |
| TC1320 | 8 | 1 | I²C | Ext | 0.8 | 10 | 350 | 0.1 | -40 to 85 | No | In Production | 8/MSOP, 8/SOIC | $0.94 |
| TC1321 | 10 | 1 | I²C | Ext | 2 | 10 | 350 | 0.1 | -40 to 85 | No | In Production | 8/MSOP, 8/SOIC | $1.22 |
| MCP4706 | 8 | 1 | I²C | Ext,VDD | 0.05 | 6 | 210 | 0.06 | -40 to 125 | Yes | In Production | 6/DFN, 6/SOT-23 | $0.52 |
| MCP4716 | 10 | 1 | I²C | Ext | 0.188 | 6 | 210 | 0.06 | -40 to 125 | Yes | In Production | 6/DFN, 6/SOT-23 | $0.60 |
| MCP4725 | 12 | 1 | I²C | Ext | 0.75 | 6 | 210 | 0.06 | -40 to 125 | Yes | In Production | 6/DFN, 6/SOT-23 | $0.70 |
| MCP4726 | 12 | 1 | I²C | Ext | 0.75 | 6 | 210 | 0.06 | -40 to 125 | Yes | In Production | 6/DFN, 6/SOT-23, 8/PDIP | $0.70 |
| MCP4728 | 12 | 4 | I²C | Int,VDD | 0.75 | 6 | 800 | 0.04 | -40 to 125 | Yes | In Production | 10/MSOP | $1.37 |
| MCP47A1 | 6 | 1 | I²C | Ext | 0.5 | 6 | 130 | 90 | -40 to 125 | Yes | In Production | 6/SC70 | $0.42 |
| MCP47DA1 | 6 | 1 | I²C | Ext,VDD | 0.25 | 6 | 130 | 90 | -40 to 125 | Yes | In Production | 6/SC70, 6/SOT-23 | $0.49 |
| MCP47FEB01 | 8 | 1 | I²C | Int,VDD,Ext | ±0.25 | 6 | 130 | 0.65 | -40 to 125 | Yes | In Production | 8/TSSOP | $0.60 |
| MCP47FEB02 | 8 | 2 | I²C | Int,VDD,Ext | ±0.25 | 6 | 260 | 0.65 | -40 to 125 | Yes | In Production | 8/TSSOP | $0.94 |
| MCP47FEB11 | 10 | 1 | I²C | Int,VDD,Ext | ±0.5 | 6 | 130 | 0.65 | -40 to 125 | Yes | In Production | 8/TSSOP | $0.74 |
| MCP47FEB12 | 10 | 2 | I²C | Int,VDD,Ext | ±0.5 | 6 | 260 | 0.65 | -40 to 125 | Yes | In Production | 8/TSSOP | $1.28 |
| MCP47FEB21 | 12 | 1 | I²C | Int,VDD,Ext | ±1.0 | 6 | 130 | 0.65 | -40 to 125 | Yes | In Production | 8/TSSOP | $1.03 |
| MCP47FEB22 | 12 | 2 | I²C | Int,VDD,Ext | ±1.0 | 6 | 260 | 0.65 | -40 to 125 | Yes | In Production | 8/TSSOP | $1.78 |
| MCP47FVB01 | 8 | 1 | I²C | Int,VDD,Ext | ±0.25 | 6 | 130 | 0.65 | -40 to 125 | Yes | In Production | 8/TSSOP | $0.49 |
| MCP47FVB02 | 8 | 2 | I²C | Int,VDD,Ext | ±0.25 | 6 | 260 | 0.65 | -40 to 125 | Yes | In Production | 8/TSSOP | $0.84 |
| MCP47FVB11 | 10 | 1 | I²C | Int,VDD,Ext | ±0.5 | 6 | 130 | 0.65 | -40 to 125 | Yes | In Production | 8/TSSOP | $0.64 |
| MCP47FVB12 | 10 | 2 | I²C | Int,VDD,Ext | ±0.5 | 6 | 260 | 0.65 | -40 to 125 | Yes | In Production | 8/TSSOP | $1.11 |
| MCP47FVB21 | 12 | 1 | I²C | Int,VDD,Ext | ±1.0 | 6 | 130 | 0.65 | -40 to 125 | Yes | In Production | 8/TSSOP | $0.94 |
| MCP47FVB22 | 12 | 2 | I²C | Int,VDD,Ext | ±1.0 | 6 | 260 | 0.65 | -40 to 125 | Yes | In Production | 8/TSSOP | $1.63 |
| MCP4801 | 8 | 1 | SPI | Int | 0.5 | 4.5 | 330 | 0.3 | -40 to 125 | Yes | In Production | 8/DFN, 8/MSOP, 8/PDIP, 8/SOIC | $0.82 |
| MCP4802 | 8 | 2 | SPI | Int | 0.5 | 4.5 | 415 | 3.3 | -40 to 125 | Yes | In Production | 8/MSOP, 8/PDIP, 8/SOIC | $1.07 |
| MCP4811 | 10 | 1 | SPI | Int | 0.5 | 4.5 | 330 | 0.3 | -40 to 125 | Yes | In Production | 8/DFN, 8/MSOP, 8/PDIP, 8/SOIC | $1.17 |
| MCP4812 | 10 | 2 | SPI | Int | 0.5 | 4.5 | 415 | 3.3 | -40 to 125 | Yes | In Production | 8/MSOP, 8/PDIP, 8/SOIC | $1.53 |
| MCP4821 | 12 | 1 | SPI | Int | 0.75 | 4.5 | 330 | 0.3 | -40 to 125 | Yes | In Production | 8/DFN, 8/MSOP, 8/PDIP, 8/SOIC | $1.66 |
| MCP4822 | 12 | 2 | SPI | Int | 0.75 | 4.5 | 415 | 3.3 | -40 to 125 | Yes | In Production | 8/MSOP, 8/PDIP, 8/SOIC | $2.17 |
| MCP48FEB01 | 8 | 1 | SPI | Int,VDD,Ext | ±0.25 | 7.8 | 130 | 0.65 | -40 to 125 | Yes | In Production | 10/MSOP | $0.60 |
| MCP48FEB02 | 8 | 2 | SPI | Int,VDD,Ext | ±0.25 | 7.8 | 250 | 0.65 | -40 to 125 | Yes | In Production | 10/MSOP | $0.94 |
| MCP48FEB11 | 10 | 1 | SPI | Int,VDD,Ext | ±0.5 | 7.8 | 130 | 0.65 | -40 to 125 | Yes | In Production | 10/MSOP | $0.74 |
| MCP48FEB12 | 10 | 2 | SPI | Int,VDD,Ext | ±0.5 | 7.8 | 250 | 0.65 | -40 to 125 | Yes | In Production | 10/MSOP | $1.28 |
| MCP48FEB21 | 12 | 1 | SPI | Int,VDD,Ext | ±1.0 | 7.8 | 130 | 0.65 | -40 to 125 | Yes | In Production | 10/MSOP | $1.03 |
| MCP48FEB22 | 12 | 2 | SPI | Int,VDD,Ext | ±1.0 | 7.8 | 250 | 0.65 | -40 to 125 | Yes | In Production | 10/MSOP | $1.78 |
| MCP48FVB01 | 8 | 1 | SPI | Int,VDD,Ext | ±0.25 | 7.8 | 130 | 0.65 | -40 to 125 | Yes | In Production | 10/MSOP | $0.49 |
| MCP48FVB02 | 8 | 2 | SPI | Int,VDD,Ext | ±0.25 | 7.8 | 260 | 0.65 | -40 to 125 | Yes | In Production | 10/MSOP | $0.84 |
| MCP48FVB11 | 10 | 1 | SPI | Int,VDD,Ext | ±0.5 | 7.8 | 130 | 0.65 | -40 to 125 | Yes | In Production | 10/MSOP | $0.64 |
| MCP48FVB12 | 10 | 2 | SPI | Int,VDD,Ext | ±0.5 | 7.8 | 260 | 0.65 | -40 to 125 | Yes | In Production | 10/MSOP | $1.11 |
| MCP48FVB21 | 12 | 1 | SPI | Int,VDD,Ext | ±1.0 | 16 | 130 | 0.65 | -40 to 125 | Yes | In Production | 10/MSOP | $0.94 |
| MCP48FVB22 | 12 | 2 | SPI | Int,VDD,Ext | ±1.0 | 7.8 | 260 | 0.65 | -40 to 125 | Yes | In Production | 10/MSOP | $1.63 |
| MCP4901 | 8 | 1 | SPI | Ext | 0.5 | 4.5 | 175 | 3.3 | -40 to 125 | Yes | In Production | 8/DFN, 8/MSOP, 8/PDIP, 8/SOIC | $0.70 |
| MCP4902 | 8 | 2 | SPI | Ext | 0.5 | 4.5 | 350 | 0.3 | -40 to 125 | Yes | In Production | 14/PDIP, 14/SOIC, 14/TSSOP | $0.93 |
| MCP4911 | 10 | 1 | SPI | Ext | 0.5 | 4.5 | 175 | 3.3 | -40 to 125 | Yes | In Production | 8/DFN, 8/MSOP, 8/PDIP, 8/SOIC | $1.00 |
| MCP4912 | 10 | 2 | SPI | Ext | 0.5 | 4.5 | 350 | 0.3 | -40 to 125 | Yes | In Production | 14/PDIP, 14/SOIC, 14/TSSOP | $1.33 |
| MCP4921 | 12 | 1 | SPI | Ext | 0.75 | 4.5 | 175 | 3.3 | -40 to 125 | Yes | In Production | 8/DFN, 8/MSOP, 8/PDIP, 8/SOIC | $1.43 |
| MCP4922 | 12 | 2 | SPI | Ext | 0.75 | 4.5 | 350 | 0.3 | -40 to 125 | Yes | In Production | 14/PDIP, 14/SOIC, 14/TSSOP | $1.90 |
| Title | |
|---|---|
| CAD/CAE Schematic Symbols and Footprints by Accelerated Designs Ultra Librarian | Download |
MCP4728 Evaluation Board Demo
The MCP4728 Evaluation Board (MCP4728EV) is a tool for quick and easy evaluation of the MCP4728 Quad Channel 12-bit Non-Volatile Digital-to-Analog Converter from Microchip Technology. The evaluation board contains the MCP4728 device and connection pins for the Microchip's popular PICkit™ Serial Analyzer. This video demonstrates the use of this evaluation board by connecting it to a PICkit™ Serial Analyzer and entering the appropriate DAC input data in the PICkit™ Serial Analyzer's PC Graphical User Interface program. The PICkit™ Serial Analyzer sends the user's data to the DAC device so that new DAC's analog outputs will be available immediately at the output pins.
MCP4728 Evaluation Board Demo
The MCP4728 Evaluation Board (MCP4728EV) is a tool for quick and easy evaluation of the MCP4728 Quad Channel 12-bit Non-Volatile Digital-to-Analog Converter from Microchip Technology. The evaluation board contains the MCP4728 device and connection pins for the Microchip's popular PICkit™ Serial Analyzer. This video demonstrates the use of this evaluation board by connecting it to a PICkit Serial Analyzer and entering the appropriate DAC input data in the PICkit Serial Analyzer's PC Graphical User Interface program. The PICkit Serial Analyzer sends the user's data to the DAC device so that new DAC's analog outputs will be available immediately at the output pins.
MCP47x6 PICtail™ Plus Daughter Board
This video provides an overview demonstration of the MCP47x6 PICtail Plus Daughter Board.
