Our external CAN controllers are economical and flexible solutions for using the SPI interface to add CAN or CAN Full Duplex (CAN FD) capability to the microcontroller (MCU) of your choice or extend the number of CAN FD channels if your MCU doesn’t have enough. We also provide devices that enable you to quickly and easily add CAN FD capability to an existing design without having to change your system MCU. Our external CAN FD controller solutions maximize reuse of your existing hardware and firmware, so you can implement the CAN FD protocol’s faster data rates and data byte message expansion in your system without a complete redesign. Our ecosystem of development tools, software and demo code will help speed up your application development and lower your design risk.

What Type of CAN Peripheral Device Do You Need?


External CAN and CAN FD Controllers

Add CAN capability or expand the number of CAN FD channels in MCUs used in automotive and industrial applications using one of these devices.

Key Benefits:

  • Flexible solution for use with any MCU
  • Support for CAN 2.0B and CAN FD networks
  • Single external component uses SPI interface to:
    • Easily add CAN FD capability to an existing design
    • Add extra CAN or CAN FD channels to an MCU
  • ISO 11898-1:2015 compliant
  • Support for wide operating range of 2.7V to 5.5V
  • Many package options available
  • High-temperature operation of -40°C to +150°C

External CAN Controllers + Transceiver

Integrating both a CAN 2.0B controller and a high-speed CAN transceiver in a single package, these devices provide a complete CAN solution that can be easily added to an MCU.

Key Benefits:

  • Minimize application component count
  • Support for CAN 2.0 networks
  • Up to 1 Mbps operation
  • Very low standby current (10 µA, typ)
  • Up to 10 MHz SPI clock speed
  • ISO 11898-1 and ISO 11898-2 compliant
  • Support for wide operating range of 2.7V to 5.5V
  • Available in 28-pin SSOP and 6 × 6 mm 28-pin QFN packages
  • Extended temperature operation of -40°C to +125°C

Featured Product


MCP2518FD External CAN FD Controller with SPI Interface

This cost-effective and small-footprint external CAN FD controller can be easily added to an MCU with an available SPI interface. It enables you to implement a CAN FD channel in an MCU that is either lacking a CAN FD peripheral or that doesn't have enough CAN FD channels for your application.

Quick Glance:

  • External CAN FD controller with support for CAN 2.0B and CAN FD networks
  • Low-power mode
  • AEC-Q100 Grade 0 and 1 qualified

CAN External Controllers


View All Parametrics
Product Status Automotive Recommended Functional Safety Ready 5K Pricing CAN FD Operating Voltage Min (V) Operating Voltage Max (V) Operating Temperature Min (C) Operating Temperature Max (C) Operating Current Max (mA) Sleep Current Max (uA) LPM Current Max (uA) Bitrate Max (MBit/s) Serial Bus Serial Bus Speed (MHz) Masks Filters Tx Buffers Rx Buffers TX FIFOs RX FIFOs TX Queue TX Event FIFO Message RAM (KB) Time Stamp (Bits) Digital I/O Max. CAN (FD) Clock (MHz) Internal CAN Clock Wettable Flanks Packages
MCP2510 Mature Product Consider: MCP2518FD No $2.36 No 3.0 5.5 -40 125 10 5 0 1 Yes 5 2 6 3 2 0 0 0 0 5 12.5 No No 18/PDIP, 18/SOIC, 20/TSSOP
MCP2515 Mature Product Consider: MCP2518FD Yes $1.64 No 2.7 5.5 -40 125 10 8 0 1 Yes 10 2 6 3 2 0 0 0 0 5 12.5 No No 18/PDIP, 18/SOIC, 20/QFN, 20/TSSOP, 20/VQFN
MCP2517FD Mature Product Consider: MCP2518FD Yes Yes $1.55 Yes 2.7 5.5 -40 150 20 550 0 8 Yes 20 32 32 0 0 31 31 1 1 2 32 2 40 No Yes 14/SOIC, 14/VDFN
MCP2518FD In Production Yes Yes $1.07 Yes 2.7 5.5 -40 150 20 550 10 8 Yes 20 32 32 0 0 31 31 1 1 2 32 2 40 No Yes 14/SOIC, 14/VDFN
