- High-performance, full-featured 3- to 52-port 1/2.5/10 Gbps Ethernet switches
- Full VLAN and Quality of Service (QoS) support
- Layer 2 and layer 3 forwarding
- Operations, Administration, Maintenance (OAM), performance monitoring, Service Activation Testing (SAT)
- MEF CE 2.0 Ethernet Virtual Connections (EVCs)
- IEEE® 1588v2 Precision Time Protocol (PTP) support
- Audio Video Bridging (AVB) and Time Sensitive Networking (TSN) support
- Access Control List (ACL) layer 2, 3, and 4 packet processing
- Fault tolerance redundancy engine
- Enhanced link diagnostics
- Low-power, energy-efficient, enhanced power management
- Flexible management via SPI, I2C, SMI or In-Band management
- Industrial (−40ºC to 85ºC) and automotive (−40ºC to 105ºC) temperature options available
Our portfolio of high-performance, small-footprint, full-featured 3- to 52-port Ethernet switches offers innovative features and robust, high-temperature operation to support applications ranging from the Internet of Things (IoT), enterprise, carrier, consumer electronics, computing, Industry 4.0 factory automation and automotive designs. Reduce your costs while speeding up your development by using our Design Check service, software drivers and turnkey application software packages.
View All Parametrics
| Product | Status | 5K Pricing | Automotive Grade | Ethernet Bandwidth | No Ethernet Ports | Interface | Fiber Support | On-Chip Termination | Cable Diagnostics | EEE | IEEE 1588 | Interrupt Pin | LEDs | Op. Voltage (V) | Vdd I/O (V) | WOL | Temp Range Min.(° C) | Temp Range Max.(° C) | Packages |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| KSZ8462 | In Production | $7.53 | No | 10/100Mbps | 3 | Host Bus | 100FX (2) | Yes | Yes | Yes | Yes | Yes | 4 | 3.3 | 1.8/2.5/3.3 | Yes | -40 | 85 | 64/LQFP |
| KSZ8463 | In Production | $3.76 | No | 10/100Mbps | 3 | MII/RMII | 100FX (2) | Yes | Yes | Yes | Yes | Yes | 4 | 3.3 | 1.8/2.5/3.3 | No | -40 | 85 | 64/LQFP |
| KSZ8563 | In Production | $5.26 | No | 10/100Mbps | 3 | MII/RMII/RGMII | No | Yes | Yes | Yes | Yes | Yes | 4 | 3.3 | 1.8/2.5/3.3 | Yes | -40 | 85 | 64/VQFN |
| KSZ8565 | In Production | $8.26 | Yes | 10/100Mbps | 5 | MII/RMII/RGMII | No | Yes | Yes | Yes | Yes | Yes | 8 | 3.3 | 1.8/2.5/3.3 | Yes | -40 | 105 | 128/TQFP |
| KSZ8567 | In Production | $6.62 | Yes | 10/100Mbps | 7 | MII/RMII/RGMII/SGMII | SGMII | Yes | Yes | Yes | Yes | Yes | 10 | 3.3 | 1.8/2.5/3.3 | Yes | -40 | 105 | 128/TQFP |
| KSZ8765 | In Production | $6.44 | No | 10/100Mbps | 5 | MII/RMII/RGMII/GMII | 100FX (2) | Yes | Yes | Yes | No | Yes | 8 | 3.3 | 1.8/2.5/3.3 | Yes | -40 | 85 | 80/LQFP |
| KSZ8775 | In Production | $3.25 | No | 10/100Mbps | 5 | MII/RMII/RGMII | No | Yes | Yes | Yes | No | Yes | 6 | 3.3 | 1.8/2.5/3.3 | Yes | -40 | 85 | 80/LQFP |
| KSZ8794 | In Production | $3.09 | No | 10/100Mbps | 4 | MII/RMII/RGMII | No | Yes | Yes | Yes | No | Yes | 6 | 3.3 | 1.8/2.5/3.3 | Yes | -40 | 85 | 64/VQFN |
| KSZ8795 | In Production | $3.20 | No | 10/100Mbps | 5 | MII/RMII/RGMII/GMII | No | Yes | Yes | Yes | No | Yes | 8 | 3.3 | 1.8/2.5/3.3 | Yes | -40 | 85 | 80/LQFP |
| KSZ8842 | In Production Consider: KSZ8852 | $7.73 | Yes | 10/100Mbps | 3 | Host Bus/PCI | No | No | Yes | No | No | Yes | 6 | 3.3 | 3.3/5.0 | No | -40 | 85 | 100/LFBGA, 128/LQFP, 128/PQFP |
| KSZ8852 | In Production | $6.71 | Yes | 10/100Mbps | 3 | Host Bus | No | Yes | Yes | Yes | No | Yes | 4 | 3.3 | 1.8/2.5/3.3 | No | -40 | 115 | 64/LQFP |
| KSZ8862 | In Production | $10.82 | Yes | 10/100Mbps | 3 | Host Bus | 100FX,FL,SX | No | Yes | No | No | Yes | 8 | 3.3 | 3.3 | No | 0 | 70 | 128/PQFP |
| KSZ8863 | In Production | $2.65 | No | 10/100Mbps | 3 | MII/RMII | 100FX (1) | No | Yes | No | No | Yes | 4 | 3.3 | 1.8/2.5/3.3 | No | -40 | 85 | 48/LQFP |
| KSZ8864 | In Production | $3.61 | Yes | 10/100Mbps | 4 | MII(2)/RMII(2) | No | Yes | Yes | No | No | Yes | 4 | 3.3 | 1.8/2.5/3.3 | No | -40 | 85 | 64/VQFN |
| KSZ8873 | In Production | $2.98 | Yes | 10/100Mbps | 3 | MII/RMII/MII(2) | 100FX (2) | No | Yes | No | No | Yes | 4 | 3.3 | 1.8/2.5/3.3 | No | -40 | 85 | 64/LQFP |
| KSZ8893 | Mature Product Consider: KSZ8863, KSZ8873 | $5.05 | Yes | 10/100Mbps | 3 | MII/RMII | 100FX,FL,SX | No | Yes | No | No | Yes | 8 | 3.3 | 2.5/3.3 | No | -40 | 85 | 100/LFBGA, 128/PQFP |
| KSZ8895 | In Production | $3.25 | Yes | 10/100Mbps | 5 | MII/RMII | 100FX (2) | Yes | Yes | No | No | Yes | 15 | 3.3 | 1.8/2.5/3.3 | No | -40 | 85 | 128/LQFP, 128/PQFP |
| KSZ8993 | Mature Product Consider: KSZ8863, KSZ8873 | $3.92 | No | 10/100Mbps | 3 | MII/RMII | 100FX (1) | No | Yes | No | No | Yes | 8 | 3.3 | 2.5/3.3 | No | -40 | 85 | 128/PQFP |
| KSZ8995 | Mature Product Consider: KSZ8895, KSZ8795 | $4.28 | No | 10/100Mbps | 5 | MII/RMII | 100FX (2) | Yes | Yes | No | No | Yes | 15 | 3.3 | 1.8/2.5/3.3 | No | -40 | 85 | 128/PQFP |
| KSZ8999 | In Production | $17.16 | No | 10/100Mbps | 9 | MII | 100FX (8) | No | No | No | No | No | 36 | 3.3 | 3.3 | n/a | -40 | 85 | 208/PQFP |
| KSZ9477 | In Production | $10.37 | No | 10/100/1000Mbps | 7 | MII/RMII/RGMII/SGMII | No | Yes | Yes | Yes | Yes | Yes | 10 | 3.3 | 1.8/2.5/3.3 | Yes | -40 | 85 | 128/TQFP |
| KSZ9563 | In Production | $5.64 | No | 10/100/1000Mbps | 3 | MII/RMII/RGMII | No | Yes | Yes | Yes | Yes | Yes | 4 | 3.3 | 1.8/2.5/3.3 | Yes | -40 | 85 | 64/VQFN |
| KSZ9567 | In Production | $8.67 | No | 10/100/1000Mbps | 7 | MII/RMII/RGMII/SGMII | No | Yes | Yes | Yes | Yes | Yes | 10 | 3.3 | 1.8/2.5/3.3 | Yes | -40 | 85 | 128/TQFP |
| KSZ9893 | In Production | $4.96 | No | 10/100/1000Mbps | 3 | MII/RMII/RGMII | No | Yes | Yes | Yes | No | Yes | 4 | 3.3 | 1.8/2.5/3.3 | Yes | -40 | 85 | 64/VQFN |
| KSZ9896 | In Production | $6.32 | No | 10/100/1000Mbps | 6 | MII/RMII/RGMII/GMII | No | Yes | Yes | Yes | No | Yes | 10 | 3.3 | 1.8/2.5/3.3 | Yes | -40 | 85 | 128/TQFP |
| KSZ9897 | In Production | $6.39 | No | 10/100/1000Mbps | 7 | MII/RMII/RGMII/SGMII | SGMII | Yes | Yes | Yes | No | Yes | 10 | 3.3 | 1.8/2.5/3.3 | Yes | -40 | 85 | 128/TQFP |
| LAN9303 | In Production | $3.97 | 10/100Mbps | 3 | MII/RMII/Turbo MII | No | No | No | No | No | Yes | 6 | 3.3 | 3.3 | No | -40 | 85 | 56/VQFN | |
| LAN9303M | In Production | $4.82 | 10/100Mbps | 3 | MII(2)/RMII(2)/Turbo MII(2) | No | No | No | No | No | Yes | 6 | 3.3 | 3.3 | No | -40 | 85 | 72/VQFN | |
| LAN9311 | In Production | $7.36 | 10/100Mbps | 3 | Host Bus | No | No | No | No | No | Yes | 12 | 3.3 | 3.3 | No | 0 | 70 | 128/TQFP | |
| LAN9312 | In Production | $8.40 | 10/100Mbps | 3 | Host Bus | No | No | No | No | No | Yes | 12 | 3.3 | 3.3 | No | -40 | 85 | 128/TQFP | |
| LAN9313 | In Production | $6.50 | 10/100Mbps | 3 | MII | No | No | No | No | Yes | Yes | 12 | 3.3 | 3.3 | No | -40 | 85 | 128/TQFP | |
| LAN9352 | In Production | $6.75 | 10/100Mbps | 3 | Host Bus/SPI/SQI | 100FX (2) | No | Yes | Yes | Yes | Yes | 6 | 3.3 | 1.8/2.5/3.3 | Yes | -40 | 85 | 80/TQFP, 72/VQFN | |
| LAN9353 | In Production | $3.64 | 10/100Mbps | 3 | MII/RMII/Turbo MII | 100FX (2) | No | Yes | Yes | Yes | Yes | 6 | 3.3 | 1.8/2.5/3.3 | Yes | -40 | 85 | 64/TQFP, 64/QFN | |
| LAN9354 | In Production | $3.41 | 10/100Mbps | 3 | RMII | 100FX (2) | No | Yes | Yes | Yes | Yes | 6 | 3.3 | 1.8/2.5/3.3 | Yes | -40 | 85 | 56/VQFN | |
| LAN9355 | In Production | $4.20 | 10/100Mbps | 3 | MII/RMII/Turbo MII | 100FX (2) | No | Yes | Yes | Yes | Yes | 6 | 3.3 | 1.8/2.5/3.3 | Yes | -40 | 85 | 80/TQFP, 88/VQFN | |
| LAN9384 | Future Product | Call for pricing | No | 10/100Mbps | 3 | MII/RMII/RGMII | No | Yes | Yes | Yes | Yes | Yes | 4 | 3.3 | 1.8/2.5/3.3 | Yes | -40 | 85 | Please call for package information |
| VSC7410 | In Production | $23.04 | No | 10/100/1000/2500Mbps | 6 | SGMII 1000Base-T (2) | 100FX, 1000X | Yes | Yes | Yes | No | Yes | 128 | 1 | 1.0/1.2/2.5 | No | -40 | 125 | 324/PBGA |
| VSC7415 | In Production | $33.35 | No | 10/100/1000/2500Mbps | 6 | SGMII 1000Base-T (2) | 100FX, 1000X | Yes | Yes | Yes | Yes | Yes | 128 | 1 | 1.0/1.2/2.5 | No | -40 | 125 | 324/PBGA |
| VSC7420 | In Production | $23.28 | No | 10/100/1000/2500Mbps | 10 | SGMII 1000Base-T (8) | 100FX, 1000X | Yes | Yes | Yes | No | Yes | 128 | 1 | 1.0/1.2/2.5 | No | -40 | 125 | 672/HSBGA |
| VSC7421 | In Production | $28.15 | No | 10/100/1000/2500Mbps | 17 | SGMII, QSGMII 1000Base-T (12) | 100FX, 1000X | Yes | Yes | Yes | No | Yes | 128 | 1 | 1.0/1.2/2.5 | No | -40 | 125 | 672/HSBGA |
| VSC7422 | In Production | $35.20 | No | 10/100/1000/2500Mbps | 25 | SGMII, QSGMII 1000Base-T (12) | 100FX, 1000X | Yes | Yes | Yes | No | Yes | 128 | 1 | 1.0/1.2/2.5 | No | -40 | 125 | 672/HSBGA |
| VSC7423 | In Production | $27.84 | No | 10/100/1000/2500Mbps | 7 | SGMII 1000Base-T (5) | 100FX, 1000X | Yes | Yes | Yes | Yes | Yes | 128 | 1 | 1.0/1.2/2.5 | No | -40 | 125 | 672/HSBGA |
| VSC7424 | In Production | $28.90 | No | 10/100/1000Mbps | 10 | SGMII 1000Base-T (8) | 100FX, 1000X | Yes | Yes | Yes | No | Yes | 128 | 1 | 1.0/1.2/2.5 | No | 0 | 125 | 672/HSBGA |
| VSC7425 | In Production | $33.23 | No | 10/100/1000Mbps | 18 | SGMII, QSGMII 1000Base-T (12) | 100FX, 1000X | Yes | Yes | Yes | No | Yes | 128 | 1 | 1.0/1.2/2.5 | No | 0 | 125 | 672/HSBGA |
| VSC7426 | In Production | $38.22 | No | 10/100/1000Mbps | 24 | QSGMII 1000Base-T (12) | No | Yes | Yes | Yes | No | Yes | 128 | 1 | 1.0/1.2/2.5 | No | 0 | 125 | 672/HSBGA |
| VSC7427 | In Production | $41.54 | No | 10/100/1000Mbps | 26 | SGMII, QSGMII 1000Base-T (12) | 100FX, 1000X | Yes | Yes | Yes | No | Yes | 128 | 1 | 1.0/1.2/2.5 | No | 0 | 125 | 672/HSBGA |
| VSC7428 | In Production | $28.35 | No | 10/100/1000/2500Mbps | 11 | SGMII 1000Base-T (8) | 100FX, 1000X | Yes | Yes | Yes | Yes | Yes | 128 | 1 | 1.0/1.2/2.5 | No | -40 | 125 | 672/HSBGA |
| VSC7429 | In Production | $68.56 | No | 10/100/1000/2500Mbps | 26 | SGMII, QSGMII 1000Base-T (12) | 100FX, 1000X | Yes | Yes | Yes | Yes | Yes | 128 | 1 | 1.0/1.2/2.5 | No | -40 | 125 | 672/HSBGA |
| VSC7430 | In Production | $36.08 | No | 10/100/1000/2500Mbps | 6 | SGMII 1000Base-T (2) | 100FX, 1000X | Yes | Yes | Yes | Yes | Yes | 128 | 1 | 1.0/1.2/2.5 | No | -40 | 125 | 324/PBGA |
| VSC7435 | In Production | $46.39 | No | 10/100/1000/2500Mbps | 6 | SGMII 1000Base-T (2) | 100FX, 1000X | Yes | Yes | Yes | Yes | Yes | 128 | 1 | 1.0/1.2/2.5 | No | -40 | 125 | 324/PBGA |
| VSC7436 | In Production | $59.28 | No | 10/100/1000/2500Mbps 10Gbps | 10 | SGMII 1000Base-T XFI | 100FX, 1000X, SFI | Yes | Yes | Yes | Yes | Yes | 128 | 1 | 1.0/1.2/2.5 | No | -40 | 125 | 324/PBGA |
| VSC7437 | In Production | $69.07 | No | 10/100/1000/2500Mbps 10Gbps | 8 | SGMII 1000Base-T XFI | 100FX, 1000X, SFI | Yes | Yes | Yes | Yes | Yes | 128 | 1 | 1.0/1.2/2.5 | No | -40 | 125 | 324/PBGA |
| VSC7438 | In Production | $84.54 | No | 10/100/1000/2500Mbps 10Gbps | 14 | SGMII, QSGMII XFI, XAUI | 100FX, 1000X, SFI | Yes | No | No | Yes | Yes | 128 | 1 | 1.0/1.2/2.5/3.3 | No | -40 | 125 | 672/HFCBGA |
| VSC7440 | In Production | $31.44 | No | 10/100/1000/2500Mbps 10Gbps | 10 | SGMII 1000Base-T XFI | 100FX, 1000X, SFI | Yes | Yes | Yes | Yes | Yes | 128 | 1 | 1.0/1.2/2.5 | No | -40 | 125 | 324/PBGA |
| VSC7442 | In Production | $66.40 | No | 10/100/1000/2500Mbps | 52 | SGMII, QSGMII | 100FX, 1000X | Yes | No | No | Yes | Yes | 128 | 1 | 1.0/1.2/2.5/3.3 | No | -40 | 110 | 672/HFCBGA |
| VSC7444 | In Production | $71.56 | No | 10/100/1000/2500Mbps 10Gbps | 26 | SGMII, QSGMII XFI, XAUI, RXAUI | 100FX, 1000X, SFI | Yes | No | No | Yes | Yes | 128 | 1 | 1.0/1.2/2.5/3.3 | No | -40 | 110 | 672/HFCBGA |
| VSC7448 | In Production | $81.87 | No | 10/100/1000/2500Mbps 10Gbps | 52 | SGMII, QSGMII XFI, XAUI, RXAUI | 100FX, 1000X, SFI | Yes | No | No | Yes | Yes | 128 | 1 | 1.0/1.2/2.5/3.3 | No | -40 | 110 | 672/HFCBGA |
| VSC7449 | In Production | $87.02 | No | 10/100/1000/2500Mbps 10Gbps | 52 | SGMII, QSGMII XFI, XAUI, RXAUI | 100FX, 1000X, SFI | Yes | No | No | Yes | Yes | 128 | 1 | 1.0/1.2/2.5/3.3 | No | -40 | 110 | 672/HFCBGA |
| VSC7464 | In Production | $115.98 | No | 10/100/1000/2500Mbps 10Gbps | 26 | SGMII, QSGMII XFI, XAUI | 100FX, 1000X, SFI | Yes | No | No | Yes | Yes | 128 | 1 | 1.0/1.2/2.5/3.3 | No | -40 | 125 | 672/HFCBGA |
| VSC7468 | In Production | $154.64 | No | 10/100/1000/2500Mbps 10Gbps | 52 | SGMII, QSGMII XFI, XAUI | 100FX, 1000X, SFI | Yes | No | No | Yes | Yes | 128 | 1 | 1.0/1.2/2.5/3.3 | No | -40 | 125 | 672/HFCBGA |
| VSC7511 | In Production | $9.79 | No | 10/100/1000/2500Mbps | 4 | SGMII 1000Base-T (4) | 100FX, 1000X | Yes | Yes | Yes | Yes | Yes | 128 | 1 | 1.0/1.2/2.5 | No | -40 | 125 | 172/VQFN |
| VSC7512 | In Production | $12.37 | No | 10/100/1000/2500Mbps | 10 | SGMII, QSGMII 1000Base-T (4) | 100FX, 1000X | Yes | Yes | Yes | Yes | Yes | 128 | 1 | 1.0/1.2/2.5 | No | -40 | 125 | 172/VQFN |
| VSC7513 | In Production | $15.46 | No | 10/100/1000/2500Mbps | 8 | SGMII, QSGMII 1000Base-T (4) | 100FX, 1000X | Yes | Yes | Yes | Yes | Yes | 128 | 1 | 1.0/1.2/2.5 | No | -40 | 125 | 256/PBGA |
| VSC7514 | In Production | $18.56 | No | 10/100/1000/2500Mbps | 10 | SGMII, QSGMII 1000Base-T (4) | 100FX, 1000X | Yes | Yes | Yes | Yes | Yes | 128 | 1 | 1.0/1.2/2.5 | No | -40 | 125 | 256/PBGA |
