ARCNET has many characteristics that make it ideal for industrial and embedded networking environments. These include its deterministic nature, its high reliability and fault tolerance, and its adaptability to a wide variety of cabling media and configurations. As the market leader in ARCNET devices, we offer a full spectrum of solutions to meet your price and performance needs.
CircLink, an ARCNET derivative, further improves on the protocol by eliminating the need for an external processor. It is optimized as a wire-replacement technology inside industrial and commercial machines.
View All Parametrics
| Product | Status | 5K Pricing | Comments | Standalone Arcnet Cntrl | MAC | PHY | TX/RX RAM Buffer(Bytes) | Deterministic Protocola (Token Passing) | Max Speed (MHz) | Op. Voltage (V) | Interface | Temp Range Min.(° C) | Temp Range Max.(° C) | Packages |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| COM20019i | In Production | $6.90 | +5V Arcnet Controller with On-Chip-RAM | N/A | Yes | No | 16K | Yes | 312.5 Kbps | 5V | RS485 | -40 | 85 | 28/PLCC |
| COM20019i3.3V | In Production | Call for pricing | 3.3V Arcnet Controller with On-Chip-RAM | N/A | Yes | No | 16K | Yes | 312.5 Kbps | 3.3V | RS485 | -40 | 85 | Please call for package information |
| COM20020i | In Production | $15.30 | +5V Arcnet Controller with On-Chip-RAM | N/A | Yes | No | 16K | Yes | 5 Mbps | 5V | RS485 | -40 | 85 | 48/TQFP, 28/PLCC |
| COM20020i3.3V | In Production | Call for pricing | 3.3V Arcnet Controller with On-Chip-RAM | N/A | Yes | No | 16K | Yes | 5 Mbps | 3.3V | RS485 | -40 | 85 | Please call for package information |
| COM20022i | In Production | $17.38 | +5V Arcnet Controller with On-Chip-RAM | N/A | Yes | No | 16K | Yes | 10 Mbps | 5V | RS485 | -40 | 85 | 48/TQFP |
| COM20022i3.3V | In Production | Call for pricing | 3.3V Arcnet Controller with On-Chip-RAM | N/A | Yes | No | 16K | Yes | 10 Mbps | 3.3V | RS485 | -40 | 85 | Please call for package information |
| HYC9088A | In Production | $27.52 | Twisted pair and COAX high impedance transceiver | N/A | No | Yes | N/A | N/A | 2.5 Mbps | + 5V /- 5V | Twisted Pair, Coax | 0 | 70 | 20/SIP |
| TMC2005 | In Production | $14.04 | 64 pin TQFP, Lead-Free, RoHS Compliant | ArcNET 5 Port HUB Controller | Repeater Logic | External | Minimal FIFO Bit Repeaterr | Yes | 10Mbps | +5V | HYC9088, HYC5000, RS485, Opt. Module, TTL Interface in Backplane Mode | 0 | 85 | 64/LQFP |
| TMC2072 | In Production | $12.51 | Peripheral mode Circlink Controller | No | Yes | No | 8K | Yes | 5 Mbps | 3.3V | RS485 | 0 | 70 | 100/LQFP |
| TMC2074 | In Production | $12.98 | Peripheral & Standalono mode Circlink Controller | Yes | Yes | No | 8K | Yes | 5 Mbps | 3.3V | RS485 | 0 | 70 | 128/TQFP |
| TMC2084 | In Production | $7.54 | Standalone mode Circlink Controller | Yes | Yes | No | N/A | Yes | 5 Mbps | 3.3V | RS485 | 0 | 70 | 48/TQFP |
