VelocityDRIVE® Software Platform (SP)
The VelocityDRIVE Software Platform (SP) is a turnkey L3 switch application for managing Microchip automotive TSN switches. It includes a binary code image that can be fully configured using the VelocityDRIVE Configuration Tool (CT). VelocityDRIVE SP is a cost-effective Real-Time Operating System (RTOS) that is designed to run on memory-constrained systems with memory requirements in the 512 KB to 2048 KB range. VelocityDRIVE SP contains full-switch feature support and offers a CORECONF/YANG-based management interface that implements standardized YANG models.
Product Features:
Standard | Feature | Specification |
802.1ASds | Networking | MAC operating in half-duplex |
802.1Qci | Networking | Per-Stream Filtering and Policing (PSFP) |
802.1Qav | Networking | Forwarding and queuing for time-sensitive streams (CBS) |
802.1Qbv | Networking | Enhancements for Scheduled Traffic (TAS) |
802.1Qbu/802.3br | Networking | Frame preemption |
802.1Qcr | Networking | Asynchronous Traffic Shaping |
Port Mirroring | Networking | Ingress and egress ports with TCAM and ACL |
Partial 802.1AS | Time Distribution | Timing and synchronization of TSN networks |
DTLS | Management | Datagram Transport Layer Security (DTLS) with pre-shared keys |
DHCP | Management | IPV4 DHCP Client |
LLDP | Management | Link layer discovery protocol |
Fast (Secure) Boot | Management | <140 ms boot from external QSPI Flash to Ethernet ready |
Deep Packet Inspection (DPI) | Management | Ingress and egress TCAM, layer two to seven with access control list |
YANG | Management | YANG status configurations and RPC support |
CoAP Management Interface (CORECONF) Server | Management | CoAP for constrained environments, including firmware updates |
MUP1 and In-Band Host Management | Management | Serial UART, SPI or IPv4 in-band host management interfaces |
Registration on MyMicrochip with enabled Secure Documents for VelocityDRIVE SP (Software Platform) and VelocityDRIVE CT (Config Tool) is recommended for automatic updates.
Related Evaluation Tools:
Documents
Title |
Title |
Document Category |
Date |
|
|---|---|---|---|---|
|
Data Sheet - 25 Aug 2026
|
VelocityDRIVE Software Package Databrief | Data Sheet | 25 Aug 2026 | Download |
|
Data Sheet - 25 Aug 2026
|
VelocityDRIVE Configuration Tool Databrief | Data Sheet | 25 Aug 2026 | Download |
|
User Guide - 25 Aug 2026
|
VelocityDRIVE Configuration Tool Users Guide | User Guide | 25 Aug 2026 | Download |
Online Assets
| Title | Title |
Category |
|---|---|---|
|
VelocityDRIVE Software Platform Documentation
User Guides
|
VelocityDRIVE Software Platform Documentation | User Guides |
|
VelocityDRIVE Software Platform Binaries
Product Documents
|
VelocityDRIVE Software Platform Binaries | Product Documents |
|
VelocityDRIVE Configuration Tool Binaries
Product Documents
|
VelocityDRIVE Configuration Tool Binaries | Product Documents |
|
Microchip Linux Binary License
Legal Documents
|
Microchip Linux Binary License | Legal Documents |
|
Standardizing Software Abstraction in Automotive Ethernet
webinar
|
Standardizing Software Abstraction in Automotive Ethernet | webinar |
Products
| Title | Product |
Title |
|---|---|---|
|
LAN9691
VelocityDRIVE® 46G Automotive TSN Multi-Gigabit Ethernet Switch
|
LAN9691 | VelocityDRIVE® 46G Automotive TSN Multi-Gigabit Ethernet Switch |
|
LAN9692
VelocityDRIVE® 66G Automotive TSN Multi-Gigabit Ethernet Switch
|
LAN9692 | VelocityDRIVE® 66G Automotive TSN Multi-Gigabit Ethernet Switch |
|
LAN9693
VelocityDRIVE® 102G Automotive TSN Multi-Gigabit Ethernet Switch
|
LAN9693 | VelocityDRIVE® 102G Automotive TSN Multi-Gigabit Ethernet Switch |
