DC-DC Integrated Switching Power Modules

Highly Integrated Low-Voltage DC-DC Switching Modules With Integrated Inductors


Our highly integrated power modules contain a controller, power switches and the necessary passive components—all of which are fully tested and pre-characterized for EMI and DC performance—to offer a complete switching power supply solution. Available in an ultra-compact, rugged and thermally enhanced package to improve high power density in your designs, these modules simplify your power design process while offering exceptional performance. Utilizing our proprietary Hyper Speed Control® architecture, they are designed to offer fast load transients to minimize output capacitance. Their HyperLight Load® mode provides efficiency improvements for light-load operation. We also offer a power module that can be used to optimize the performance of your FPGA-based design.

Featured Products


MCPF1525

MCPF1525

16V, 25A Stackable Switching Buck Regulator Module

    • 16V supply, 25A load capability (stackable up to 200A)
    • Small Land Grid Array (LGA) package 6.8 × 7.65 × 3.85 mm
    • Low conducted and radiated noise
    • Operating temperature range of −40°C to +125°C
    • Programmable using I2C and PMBus®
    MCPF1412

    MCPF1412

    16V, 12A Switching Buck Regulator Module

    • 16V supply, 12A load capability
    • Small LGA package 5.8 × 4.9 × 1.6 mm
    • Low conducted and radiated noise
    • Operating temperature range of −40°C to +125°C
    • Programmable using I2C and PMBus®
    MCPF1606A

    MCPF1606A

    16V, 6A Switching Buck Regulator Module

    • 16V supply and 6A load capability
    • Small LGA package 3.3 × 3 mm, 3 × 1.35 mm
    • Low conducted and radiated noise
    • Operating temperature range of –40°C to +125°C
    • Programmable through I2C

    MIC45M235

    16V, 35A Switching Buck Regulator Module

      • 16V, 35A load capability
      • Resistor programmable output 0.6V to 1.8V
      • Pin-selectable valley current or voltage mode
      • Fast transient response
      • Overcurrent, overvoltage, thermal shutdown
      • Remote output sensing for improved accuracy
      • ​11 × 17 × 6.46 mm LGA package​
      • Junction temperature range​ of –40°C to +125°C

      Why Choose Our DC-DC Low-Voltage Modules?


      Ease of Use

      • Turnkey solution speeds your time to market
      • Integrated controller, inductor and MOSFETs for simplified design
      • Optimized pinout for easy layout and assembly

      Exceptional Performance

      • Up to 93% power conversion efficiency
      • Low radiated emissions (EMI)
      • Hyper Speed Control architecture fast load transient response

      Small Form Factor

      • Small QFN package reduces solution size
      • Uses up to 60% less board space versus discrete designs
      • Low height profile (down to 0.9 mm)

      Robust

      • Rugged package design for thermal performance, vibration and humidity resistance
      • Fewer external components improve reliability
      • Fully specified from −40°C to +125°C

      Design Resources


      MPLAB Analog Designer

      MPLAB® Analog Designer

      This tool provides design suggestions for common circuit needs, estimates performance for common modifications, and can export to MPLAB® Mindi™ Analog Simulator for verification.

      MPLAB Mindi Analog Simulator

      MPLAB® Mindi™ Analog Simulator

      This simulation tool uses a SIMetrix/SIMPLIS environment to model circuit behavior, reducing design time with software debugging for initial design verification.

      MicroCHECK Design Service

      MicroCHECK Design Service

      Our complimentary MicroCHECK design review service, which offers insight from the initial concept to the final PCB layout, is available to customers who are using our products in their projects.
