Reverse Power Feed (RPF) Products

View All Parametrics

RPF Solutions for Shared Power Delivery, SPE-DPU Signalling and Per-Line Monitoring and Control

Reverse Power Feed (RPF) is a critical technology for the upgrade of VDSL2 subscribers to the G.fast standard, which has a maximum range, at high speeds, of 250m. Our RPF solution simplifies the complexity of powering a low-port-count Distribution Point Unit (DPU) by providing power from the Customer Premises Equipment (CPE) rather than from local AC mains or other remote feeding. Our RPF chipsets support power feeding from CPEs and shared power delivery and extraction at the DPU. In addition to the powering function, the firmware also manages PSE-DPU signaling, power sharing, per-line monitoring and control.

RPF Products

Power Sourcing Equipment (PSE) for CPEs

  • Supports main requirements of ETSI TS 101 548 V2.1.1 PSE, multi-class support
  • PSE-DPU signaling generation
  • Supports SR1 (10W), SR2 (15W), SR3 (21W) power sourcing
  • Field upgradable
Explore PD81101

Powered Extractor (PE) for DPUs

  • Reverse polarity protection
  • Up to 16 lines FairPower™ sharing
  • PSE-DPU signaling detection and decoding
  • Battery backup support
  • Per-line monitoring and control capabilities
  • Supports low-power mode
  • Field upgradable
Explore PD82000

Design Resources

MPLAB Analog Designer

MPLAB® Analog Designer

This tool provides design suggestions for common circuit needs, estimates performance for common modifications, and can export to MPLAB® Mindi™ Analog Simulator for verification.

Learn More
MPLAB Mindi Analog Simulator

MPLAB® Mindi™ Analog Simulator

This simulation tool uses a SIMetrix/SIMPLIS environment to model circuit behavior, reducing design time with software debugging for initial design verification.

Learn More
MicroCHECK Design Service

MicroCHECK Design Service

Our complimentary MicroCHECK design review service, which offers insight from the initial concept to the final PCB layout, is available to customers who are using our products in their projects.

Learn More
