30 kW SiC-Based Polymorphic DC-DC Converter Reference Design

This reference design is no longer supported.

Buy Now

Key Features

This reference design is no longer available. Please visit our Reference Design Library to explore our current portfolio of supported solutions.

For the latest SiC-based solutions, please refer to our SiC Hardware Resources page.

Title
30 kW Polymorphic DC-DC Converter Brochure	Download

mSiC Products and Solutions

Reference Design BOM


Part Number	Product Type	Description

MSC050SDA120	1200V Silicon Carbide (SiC) Schottky Barrier Diodes (SBDs)	1200V Silicon Carbide (SiC) Schottky Barrier Diodes (SBDs)
MSC010SDA120	1200V Silicon Carbide (SiC) Schottky Barrier Diodes (SBDs)	1200V Silicon Carbide (SiC) Schottky Barrier Diodes (SBDs)
dsPIC33CK256MP506	100MHz High-Performance DSC	100 MHz Single-Core 16-bit Digital Signal Controller (DSC) designed for motor control and digital power applications
MCP3221	12-Bit, 22kSPS, Single Channel ADC w/I2C™	12-bit, 22 ksps ADC in small SOT-23 package
MCP6V51	45V, 2 MHz Zero-Drift Op Amp w/ EMI Filtering	2 MHz, 45V, Single Zero-Drift Op Amp
MCP6021	Rail-to-Rail Input/Output, 10 MHz Op Amps	10MHz, Single, Precision Op Amp
MCP1501	High Precision Buffered Voltage Reference	0.10% precision buffered voltage reference
MIC39100	1.0A 1.0% Fixed Voltage LDO	1.0A 1.0% Fixed Voltage LDO
ATA6561	High-speed CAN FD Transceiver with Standby Mode and VIO Pin	ATA6561
