HDMI®

Our HDMI® 2.0 solution for PolarFire® FPGAs and PolarFire SoCs supports 4K resolutions at up to 60 fps, HDMI-to-SDI cross-conversion and loopback designs. It has been successfully deployed in video converters in video converters and a wide range of commercial and industrial applications.

FPGAs for Smart Robotics

FPGAs for Medical Imaging

FPGAs for Automotive

Supported Families and IP Licensing Requirements

FeaturesHDMI RxHDMI Tx
Supported Families

PolarFire® FPGAs and PolarFire SoC FPGAs

PolarFire® FPGAs and PolarFire SoC FPGAs

Licensing Requirements

Free to use: The encrypted IP and Libero® Silver licenses are available at no cost.

Click here to learn about Libero licensing.

Free to use: The encrypted IP and Libero® Silver licenses are available at no cost.

Click here to learn about Libero licensing.

RTLContact UsContact us
Key IP FeaturesLearn More about HDMI Rx IPLearn More about HDMI Tx IP

Evaluation Options

Summary

Evaluation Options

Kits Required

Short Description

Additional Requirements

Supported Families

SDI-to-HDMI video conversion

VIDEO-DC-SDI +
MPF300-VIDEO-KIT-NS

SDI-to-HDMI 4K60 converter with dynamic rate support and audio passthrough for real-time video translation

SDI source, HDMI monitor

PolarFire® FPGA and

PolarFire SoC FPGA

HDMI-to-SDI video conversion

VIDEO-DC-SDI +
MPF300-VIDEO-KIT-NS

HDMI-to-SDI 4K60 converter with dynamic rate support and audio

SDI monitor, HDMI source

PolarFire FPGA

PolarFire SoC FPGA

HDMI loopbackMPF300-VIDEO-KIT-NSCaptures video and audio via the HDMI 2.0 RX port, decodes them, buffers the data in FIFOs and loops it out through the HDMI 2.0 TX port to an external source or monitorHDMI monitor with audio support

PolarFire FPGA

PolarFire SoC FPGA

SDI-to-HDMI video conversion on PolarFire FPGA

  • Automatically detects and adapts to various SDI data rates (1.5G, 3G, 6G and 12G) and input resolutions (such as 720p50/30, 1080p and 4K)
  • Dynamically reconfigures in real time to enable seamless video output on the HDMI sink without manual intervention or system reset
HDMI Rx IP
HDMI Rx Application Note
PolarFire Video Kit
SDI FMC

HDMI-to-SDI video conversion on PolarFire FPGA

  • Automatically detects and adapts to various HDMI input resolutions
  • Dynamically reconfigures, in real time, to video output on the SDI sink
  • Supports multiple SDI data rates (1.5G, 3G, 6G and 12G) without manual intervention or system reset
HDMI Tx IP
HDMI Tx Application Note
PolarFire Video Kit
SDI FMC

HDMI loopback

  • Demo shows HDMI 2.0 RX/TX video loopback on the PolarFire® FPGA Video Kit
  • Supports dynamic resolutions from 720p30 to 4K60
  • Captures, decodes, buffers and loops out HDMI video/audio via HDMI 2.0 TX
Need IP
Need IP Application Note
PolarFire Video Kit
PolarFire SoC Video Kit

SDI FMC

This FMC daughter card is a hardware evaluation platform for evaluating and testing the Serial Digital Interface (SDI) IP.

PolarFire Video Kit

Evaluate 4K image processing and rendering using dual camera sensors, numerous display interfaces and popular imaging and video protocols including MIPI CSI-2 TX, MIPI CSI-2 RX, HDMI 1.4 TX, HDMI 2.0, DSI and HD/3G SDI.
