Our DisplayPort technology enables high-bandwidth, low-latency video and audio transmission for embedded and industrial systems. Commonly used with our PolarFire® FPGAs and PolarFire SoC FPGAs, it supports real-time image processing; AI-based vision and high-resolution, multidisplay systems up to 8K.
DisplayPort IP cores and PHYs offer flexible source (Tx) and sink (Rx) options for applications like industrial panels, defense displays, avionics instrumentation and medical imaging. With low-power, long-term reliability and FPGA integration efficiency, our DisplayPort solutions provide robust, scalable and future-ready video interfaces for advanced embedded; edge AI and mission-critical, display-driven designs.
FPGAs for Smart Robotics
FPGAs for Medical Imaging
FPGAs for Automotive
- Display Port Tx
- Display Port Rx
DisplayPort Transmitter (Tx) on PolarFire FPGA
- Implements DisplayPort 1.4-compliant Tx IP for high-speed video transmission
- Supports data rates from 1.62 Gbps to 8.1 Gbps, which is an excellent choice for diverse display applications
- Demonstrates video streaming using the PolarFire Video Kit and a dual-sensor camera module
- Developed and tested using our Libero® SoC software for rapid prototyping
- Enables engineers to evaluate and prototype DisplayPort Tx solutions for advanced embedded vision systems
DisplayPort Receiver (Rx) on PolarFire FPGA
- Implements DisplayPort 1.4 compliant receiver IP for video input applications
- Supports multiple data rates: 1.62 Gbps, 2.7 Gbps, 5.4 Gbps and 8.1 Gbps
- Demonstrates real-time video capture and processing using the PolarFire Video Kit
- Built with Libero® SoC software for seamless design and integration
- Enables developers to evaluate PolarFire FPGA for smart embedded vision and rapid prototyping
DisplayPort FMC
The DisplayPort daughter card is a platform used to implement high-performance video transmission using the DisplayPort standard and our PolarFire® FPGAs.
PolarFire Video Kit
Evaluate 4K image processing and rendering using dual camera sensors, numerous display interfaces and popular imaging and video protocols including MIPI CSI-2 TX, MIPI CSI-2 RX, HDMI 1.4 TX, HDMI 2.0, DSI and HD/3G SDI.
