PCIe^® Peripherals

Download PCIe Peripherals Brochure

View All Parametrics

Flexible PCIe Fanout Switch for Industrial Applications

Our single-chip PCIe Gen 4.0 (at 8 GT/s) fanout switch features highly integrated peripherals for seamless connectivity. This compact yet powerful switch includes an embedded USB 3.2 Gen 2 (10G) host controller, 2.5G Ethernet MAC and programmable I/O, making it a versatile solution for diverse applications.

With integrated PCIe physical interfaces that offer multi-speed and multi-lane ports, the PCI11xxxC/PCI12xxxC family addresses the growing demand for higher-bandwidth PCIe subsystems in embedded applications. These devices can deliver PCIe upstream across a single lane or multiple lanes to accommodate varying system bandwidths. Combined with a modern design approach, these devices provide both diagnostics and power savings and they feature extended industrial temperature grades with options for automotive-qualified devices.

PCIe Peripheral Products

PCI11414C

Single-chip PCIe switch with an integrated USB 3.2 Gen 2 host controller, 2.5G Ethernet MAC and programmable I/O

Explore PCI11414C

PCI11400C

Single-chip PCIe switch with an integrated USB 3.2 Gen 2 10G host controller and programmable I/O

Explore PCI11400C

PCI11101C

Single-chip PCIe switch with an integrated USB 3.2 Gen 2 10G host controller and programmable I/O

Explore PCI11101C

PCI11010C

Single-chip PCIe switch with an integrated Ethernet MAC and programmable I/O

Explore PCI11010C

PCI12000C

Single-chip 3-port PCIe switch with an integrated programmable I/O

Explore PCI12000C

Webinar

The Future of Connectivity: PCIe Peripherals Offering Multiple Interfaces for a Wide Range of Applications

Join us for an insightful session where we discuss our latest family of PCIe expansion devices. We will explore how these devices empower current generation processors to transcend traditional limitations, accessing industrial-grade networking and USB capabilities.

Watch Webinar

Key Applications

Industrial Control

Robotics

AIoT Edge Computing

Tools and Software

Demo & Evaluation Boards
Software

EVB-PCI11414

The EVB-PCI11414 is a demonstration and evaluation platform that provides the necessary requirements and interface options for evaluating the PCI11414.

EVB-PCI11400

The EVB-PCI11400 is a demonstration and evaluation platform that provides the necessary requirements and interface options for evaluating the PCI11400.

EVB-PCI11101

The EVB-PCI11101 is a demonstration and evaluation platform that provides the necessary requirements and interface options for evaluating the PCI11101.

EVB-PCI11010

The EVB-PCI11010 is a demonstration and evaluation platform that provides the necessary requirements and interface options for evaluating the PCI11010.

EVB-PCI12000

The EVB-PCI12000 is a demonstration and evaluation platform that provides the necessary requirements and interface options for evaluating the PCI12000.

MPLAB Connect Configurator

MPLAB® Connect Configurator (formerly ProTouch2) is a configuration and programming tool that makes it easy for you to configure and program our latest USB hubs, and Ethernet and PCIe® products.
