Pre-provisioned secure element for LoRaWAN
Overview
- Device Name:ATECC608B-TNGLORA
- Algorithm Type:ECC-P256 (ECDH and ECDSA), SHA256, AES128-GCM
- Standby Typical (uA):0.03
- Provisioning:Trust&GO
- Interface Type:Single-wire; I2C
The Microchip ATECC608B-TNGLORA is a Trust&GO secure element part of the Trust Platform for the CryptoAuthentication family. The device comes pre-configured and pre-provisioned with the authentication keys of The Things Industries (TTI) join servers. The configuration and credentials are locked in the device and cannot be changed unless a re-keying is requested to the TTI join server to move the device to a different join server than TTI. The TTI join server is agnostic of the network server or application server either it's a public or private network. This secure element integrates an AES128 hardware accelerator and hardware-based cryptographic key storage as well as cryptographic countermeasures which reduces potential backdoors linked to software weaknesses on the symmetric LoRaWAN authentication keys. Other important feature integrated in the ATECC608B-TNGLORA are the ECDH (Elliptic Curve Diffie Hellman) security protocol an ultra-secure method to provide key agreement for encryption/decryption, along with ECDSA (Elliptic Curve Digital Signature Algorithm) sign-verify authentication for the Internet of Things (IoT) market including home automation, industrial networking, medical, or retails.
The device is agnostic of any microprocessor (MPU) or microcontroller (MCU) and compatible with virtually any MCUs or MPUs thanks to the CryptoAuthLib library. As with all CryptoAuthentication devices, the ATECC608B-TNGLORA delivers extremely low-power consumption, requires only a single GPIO over a wide voltage range, and has a tiny form factor making it ideal for a variety of applications that require longer battery life and flexible form factors.
The device is agnostic of any microprocessor (MPU) or microcontroller (MCU) and compatible with virtually any MCUs or MPUs thanks to the CryptoAuthLib library. As with all CryptoAuthentication devices, the ATECC608B-TNGLORA delivers extremely low-power consumption, requires only a single GPIO over a wide voltage range, and has a tiny form factor making it ideal for a variety of applications that require longer battery life and flexible form factors.
Cannot load image!
Not the part you were looking for?
Tools And Software
Demo & Evaluation Boards
| Tools |
|---|
 The SAM R34 Xplained Pro Evaluation Kit is a certified LoRa evaluation board for developing with SAM R34 Family of LoRa SiP devices.
|
 The AT88CKSCKTSOIC-XPRO is an XPRO extension board that attaches 8-pin SOIC CryptoAuthentication™ devices to Microchip MCU's that support an XPRO interface. All Microchip CryptoAuthentication™ devices regardless of interface can be used with this board.
|
["developmentenvironment","Development Environment"] ,
["emulators","Emulator and Debuggers"] ,
["demoevaluationboards","Demo & Evaluation Boards"] ,
["programmerrelations","Programmers"] ,
["thirdpartytools","3rd Party Tools"] ,
["legacy","Legacy"] ,
["softwarelibraries","Library and Firmware"]
referencedesigns,Reference Designs:
ibisboarddesignfiles,Board Design Files:
spicemodels,Spice Models:
plecsmodels,PLECS Models:
bootloaders,Bootloaders:
Purchase
Loading
Catalog Parts for ATECC608B-TNGLORA
All parts
|
|
|
|
|
|
|
|||
|---|---|---|---|---|---|---|---|---|
| ATECC608B-TNGLORAS-B | 8 | SOIC | -40C to +85C | TUBE | $1.58 | Order Incoming Factory Stock Now | Please select a different part available in this familyView Samples | |
| Trust & Go LORAWAN, Provisioned Proto Typing, 8-SOIC, I2C, (10 bulk) Country of Origin: Order Incoming Factory Stock Now Additional Stock Arriving. You can secure stock by ordering now, and we will ship the product up to the ordered quantities on the dates given below. Incoming Factory Stock. Order Now to Secure Up to 3563 partial units estimated to ship on This lead time represents a snapshot in time. Actual delivery may vary depending on order timing, volume, and other factors. Microchip remains committed to meeting or improving our committed dates to the best of our ability.Lead Time For Additional Quantities Additional quantities estimated to ship by | ||||||||
| ATECC608B-TNGLORAU-B | 8 | UDFN | -40C to +85C | BAG | $1.58 | In Stock Now | Please select a different part available in this familyView Samples | |
| Trust & Go LORAWAN, Provisioned Proto Typing, 8-UDFN, I2C, (10 bulk) Country of Origin: In Stock Now: 170 Full BAG Up to 170 full units estimated to ship on Additional Stock Arriving. You can secure stock by ordering now, and we will ship the product up to the ordered quantities on the dates given below. Incoming Factory Stock. Order Now to Secure Up to 2160 full units estimated to ship on Up to 115 partial units estimated to ship on Up to 10000 partial units estimated to ship on Up to 10000 partial units estimated to ship on Up to 10000 partial units estimated to ship on Show More This lead time represents a snapshot in time. Actual delivery may vary depending on order timing, volume, and other factors. Microchip remains committed to meeting or improving our committed dates to the best of our ability.Lead Time For Additional Quantities Additional quantities estimated to ship by | ||||||||
| ATECC608B-TNGLORAU-C | 8 | UDFN | -40C to +85C | T/R | $1.26 | In Stock Now | Please select a different part available in this familyView Samples | |
| Trust & Go LORAWAN, Provisioned, 8-SOIC, I2C, (100 unit multiple) Country of Origin: In Stock Now: 170 Full Tape and Reel Up to 170 full units estimated to ship on Additional Stock Arriving. You can secure stock by ordering now, and we will ship the product up to the ordered quantities on the dates given below. Incoming Factory Stock. Order Now to Secure Up to 2160 full units estimated to ship on Up to 115 partial units estimated to ship on Up to 10000 partial units estimated to ship on Up to 10000 partial units estimated to ship on Up to 10000 partial units estimated to ship on Show More This lead time represents a snapshot in time. Actual delivery may vary depending on order timing, volume, and other factors. Microchip remains committed to meeting or improving our committed dates to the best of our ability.Lead Time For Additional Quantities Additional quantities estimated to ship by | ||||||||
| ATECC608B-TNGLORAU-G | 8 | UDFN | -40C to +85C | T/R | $1.02 | In Stock Now | Please select a different part available in this familyView Samples | |
| Trust & Go LORAWAN, Provisioned, 8-UDFN, I2C, 2K multiple Country of Origin: In Stock Now: 170 Full Tape and Reel Up to 170 full units estimated to ship on Additional Stock Arriving. You can secure stock by ordering now, and we will ship the product up to the ordered quantities on the dates given below. Incoming Factory Stock. Order Now to Secure Up to 2160 full units estimated to ship on Up to 115 partial units estimated to ship on Up to 10000 partial units estimated to ship on Up to 10000 partial units estimated to ship on Up to 10000 partial units estimated to ship on Show More This lead time represents a snapshot in time. Actual delivery may vary depending on order timing, volume, and other factors. Microchip remains committed to meeting or improving our committed dates to the best of our ability.Lead Time For Additional Quantities Additional quantities estimated to ship by | ||||||||
| ATECC608B-TNGLORAS-C | 8 | SOIC | -40C to +85C | T/R | $1.26 | Order Incoming Factory Stock Now | Please select a different part available in this familyView Samples | |
| Trust & Go LORAWAN, Provisioned, 8-SOIC, I2C, (100 unit multiple) Country of Origin: Order Incoming Factory Stock Now Additional Stock Arriving. You can secure stock by ordering now, and we will ship the product up to the ordered quantities on the dates given below. Incoming Factory Stock. Order Now to Secure Up to 3563 partial units estimated to ship on This lead time represents a snapshot in time. Actual delivery may vary depending on order timing, volume, and other factors. Microchip remains committed to meeting or improving our committed dates to the best of our ability.Lead Time For Additional Quantities Additional quantities estimated to ship by | ||||||||
| ATECC608B-TNGLORAS-G | 8 | SOIC | -40C to +85C | T/R | $1.02 | Order Incoming Factory Stock Now | Please select a different part available in this familyView Samples | |
| Trust & Go LORAWAN, Provisioned, 8-SOIC, I2C, 2K multiple Country of Origin: Order Incoming Factory Stock Now Additional Stock Arriving. You can secure stock by ordering now, and we will ship the product up to the ordered quantities on the dates given below. Incoming Factory Stock. Order Now to Secure Up to 3563 partial units estimated to ship on This lead time represents a snapshot in time. Actual delivery may vary depending on order timing, volume, and other factors. Microchip remains committed to meeting or improving our committed dates to the best of our ability.Lead Time For Additional Quantities Additional quantities estimated to ship by | ||||||||
