Overview
Generic socketcard for devices in TQFP32 package, 0.8 Pitch, 7x7 Body Size
For an overview of card combinations and supported devices see Device Support Table
Generic socket card for devices in TQFP32 package, 0.8 Pitch, 7x7 Body Size
Socket card PCB assembly
Cannot load image!
| Tool Details |
|---|
Routing card for the 32-pin megaAVR® in TQFP and QFN socket supplements the STK600 Starter Kit.
|
Routing card for the 32-pin megaAVR® in TQFP and QFN socket supplements the STK600 Starter Kit.
|
Routing card for SAM D20 in 32-pin TQFP and QFN socket.
|
Routing card for SAM D21 in 32-pin TQFP and QFN socket.
|
Routing card for SAM D21L in 32-pin QFN or TQFP socket.
|
Routing card for the 32-pin megaAVR® in TQFP socket supplements the STK600 Starter Kit.
|
Routing card for the 32-pin megaAVR® in TQFP socket supplements the STK600 Starter Kit.
|
Routing card for the 32-pin tinyAVR® in TQFP and QFN socket supplements the STK600 Starter Kit.
|
Routing card for the 32-pin tinyAVR® in TQFP or QFN socket supplements the STK600 Starter Kit.
|
STK600 routing card for XMEGA® 32-pin TQFP and QFN socket. Supplements STK600.
|
Routingcard for 32-pin SAM L21 series in TQFP and QFN socket
|
