SAM9X7 Series

Hybrid MCUs for Creating Low-Cost, Low-Power Graphics and Other Applications

Our SAM9X7 series hybrid MCUs are low-power and cost-optimized Arm926EJ-S™ core based microprocessors (MPUs) that run up to 800 MHz. These devices include a powerful set of peripherals for connectivity and user interface applications such as MIPI® DSI® and Low-Voltage Differential Signaling (LVDS) with 2D graphics, MIPI CSI-2® cameras, and Gigabit Ethernet with Time-Sensitive Networking (TSN) and CAN FD support. SAM9X7 MPUs also offer advanced security functions like tamper detection, secure boot, secure key storage, True Random Number Generator (TRNG), Physically Unclonable Functions (PUFs) and higher-performance crypto accelerators for Advanced Encryption Standard (AES) and Secure Hash Algorithm (SHA).

Built-in DDR2/3(L) and QSPI Flash support makes SAM9X7 a great platform for user interface applications such as HMI-based clusters, thermostats, Electric Vehicle (EV) chargers and connected devices like control panels and secure IoT gateways. The low-power features and small packages are well-suited for wearables and other battery-operated consumer devices.

SAM9X7 Series Overview

Features SAM9X70 SAM9X72 SAM9X75
Core  Arm926EJ-S @ 800 MHz Arm926EJ-S @ 800 MHz Arm926EJ-S @ 800 MHz
Package 11x11 ², 0.65-mm pitch, 240-ball BGA,9x9 mm², 0.5-mm pitch, 256-ball BGA 11x11 ², 0.65-mm pitch, 240-ball BGA,9x9 mm², 0.5-mm pitch, 256-ball BGA 11x11 ², 0.65-mm pitch, 240-ball BGA,9x9 mm², 0.5-mm pitch, 256-ball BGA
LCD, GFX2D No LVDS, parallel port LVDS, MIPI DSI, parallel port
Camera Interface (ISC) Parallel port Parallel port MIPI CSI2, parallel port
GMAC 10/100/1000 Mbps with IEEE-1588 and TSN support 10/100/1000 Mbps with IEEE-1588 and TSN support 10/100/1000 Mbps with IEEE-1588 and TSN support
USB 3 (3 hosts or 2 hosts/1 device) 3 (3 hosts or 2 hosts/1 device) 3 (3 hosts or 2 hosts/1 device)
Cryptography AES/TDES/SHA/TRNG AES/TDES/SHA/TRNG AES/TDES/SHA/TRNG
Feature SAM9X75D5M SAM9X75D1G SAM9X75D2G
Core Arm926EJ-S @ 800 MHz Arm926EJ-S @ 800 MHz Arm926EJ-S @ 800 MHz
Package BGA243, 16x16mm², pitch 0.8 mm BGA243, 16x16mm², pitch 0.8 mm BGA243, 16x16mm², pitch 0.8 mm
8-bit NAND interface Yes Yes Yes
DRAM  512 Mbit DDR2  1 Gbit DDR3L  2 Gbit DDR3L
 Ambient Temperature –40°C to +105°C –40°C to +85°C –40°C to +85°C
Features SAM9X75D2GN4 SAM9X75D1GN2 SAM9X75D5MN0
Core Arm926EJ-S @ 800 MHz Arm926EJ-S @ 800 MHz Arm926EJ-S @ 800 MHz
DRAM 1–2 Gb DDR3L memory 1 Gb DDR3L memory 512 Mb DDR2 memory
NAND Flash 2–4 Gb 2 Gb NAND –
Gb Ethernet PHY Yes (LAN8840T) Yes (LAN8840T) Yes (LAN8840T)
PMIC Yes (MCP16502) Yes (MCP16502) Yes (MCP16502)
Package 35 × 30 mm, 174-pin, 0.65 mm pad pitch 35 × 30 mm, 174-pin, 0.65 mm pad pitch 35 × 30 mm, 174-pin, 0.65 mm pad pitch

Getting Started

Visit our Developer Help website to access a complete suite of development resources for the SAM9X7 family including reference designs, software packages, hardware documentation and in-depth boot process.

Developer Help Graphic

Tools and Software

Part Number: Quantity: Price per Unit (in USD): Total Amt:
Continue Shopping Go to Cart
EV31H43A
SAM9X75 Curiosity LAN Kit

The SAM9X75 Curiosity Development Board features a SAM9X75D2G MPU and is the evaluation platform for the SAM9X7 Series MPU devices.

View Purchasing Options

MPLAB Harmony Graphic

MPLAB® Harmony v3

MPLAB Harmony v3 is a fully integrated embedded software development framework that provides flexible and interoperable software modules to simplify the development of value-added features and reduce your product’s time to market.

Learn More
Linux Graphic

Linux® OS

Explore our mainline Linux distribution, which powers our MPUs and hybrid MCUs while leveraging a vast open-source community.

Learn More
Zephyr Logo

Zephyr®

Zephyr is a cutting-edge, open-source Real-Time Operating System (RTOS). We offer a variety of products and development tools that support this RTOS.

Learn More

Microchip University Online Learning

Soldering a PCB Board

MPU System and PCB Design Pitfalls and Solutions

This couse covers general system design topics such as hardware design, core, peripherals, bootloaders, clocking and timing, signal integrity and PCB design.

Register for Course
Linux

Building Your Linux Development System

This course leads you through the steps of setting up a Linux® development computer, interfacing to sensors, creating graphics and building your own software distribution.

Register for Course

Solutions

Microchip Graphics Suite Image

Graphics

Differentiate your products with our aesthetically pleasing and feature-rich embedded Graphical User Interfaces (GUIs) that offer intuitive menus, vivid graphics and easy device interaction

Learn More
Automotive Interior Concept Image

Automotive

Our 32-bit MPU-based solutions meet the demands of modern in-car systems, including control panels, gateways, telematics and audio applications. These MPUs are AEC-Q100 Grade 2 qualified and supported by our client-driven obsolescence policy to enable long-term availability and reliability.

Learn More
Industrial Automation Concept Image

Industrial Automation Communications

Accelerate your industrial automation design with robust, real-time Industrial communication stacks that are seamlessly supported on our MPUs.

Learn More

Design Help

Need Help Choosing a Product for Your Design?

Our Client Support team is here to support you. Use the link below to schedule a call with a member of our team, use our live chat widget in the bottom right corner or submit a question for assistance and we will follow up with you as soon as possible.











MPU Design Partners

We partner with design consultants to assist with your MPU-based designs. Learn more about how our design partners can accelerate your time to market.

Design Partners
