Overview
The PIC32-BZ6 Curiosity Board is a full-featured development platform designed to accelerate evaluation and prototyping with the PIC32-BZ6 family of wireless MCUs. Featuring Bluetooth LE and Thread connectivity, this board brings out the full potential of the PIC32WM-BZ6204UE module and PIC32CX2051BZ62132 SoC making it a good choice for a wide range of connected applications in industrial, automotive and consumer markets.
Product Features:
- High-performance MCU: 128 MHz ARM® Cortex®-M4F core with 2 MB Flash and 512 KB RAM
- Multiprotocol wireless: Bluetooth LE, Thread, Matter and multiprotocol support for flexible, future-proof connectivity
- Versatile peripherals: Dual CAN-FD ports, 10/100 Mbps Ethernet, full-speed USB, QEI for motor control, touch sensing and graphics
- Enhanced security: Immutable secure boot ROM and on-board hardware security engine with AES, SHA, ECC, and TRN
- Automotive and industrial ready: AEC-Q100 Grade 1 qualification for reliable operation in harsh environments
Board Highlights:
- All I/Os accessible: comprehensive pinout for evaluating every MCU feature
- Expansion options:
- 2x mikroBUS™ sockets for MikroElektronika CLICK™ boards
- Xplained Pro header for additional extension board
- GFX connector for graphics evaluation
- Convenient connectivity:
- USB Type-C interface for power and programming
- RMII for Ethernet
- CAN FD
- Development ecosystem: Supported by MPLAB® IDE and Zephyr® RTOS, with proven reference designs and code examples to jumpstart your project
- On-board temperature sensor for environmental monitoring
- USB Type-C interface for power and programming
The PIC32-BZ6 Curiosity Board streamlines your development process, helping you bring secure, connected products to market faster.
Getting Started: PIC32-BZ6 Curiosity Board User's Guide
- PIC32WM-BZ6204UE wireless microcontroller module supporting Bluetooth®, Thread®, Matter and proprietary protocols
- mikroBUS™ socket and XPRO header for add-on and expansion boards
- On-board programmer/debug circuit
- One reset switch, one user configurable switch and one user LED controlled by PWM
- USB or Li-Po battery powered with management and charger
- PIC32-BZ6 Curiosity Board
- 1x antenna (external and detachable)
Cannot load image!
Documentation
Filter by Document Type
Search Documentation
|
Title
|
Document Category
|
|||
|---|---|---|---|---|
| PIC32-BZ6 Curiosity Board User's Guide | User Guides | PDF | HTML | ||
| PIC32CX-BZ6 and PIC32WM-BZ6 Family Data Sheet | Data Sheets | PDF | HTML | ||
| PIC32CX-BZ6 Family Silicon Errata | Errata | PDF | HTML | ||
| PIC32CX-BZ6 Programming Specification | Programming Specifications | PDF | HTML | ||
| EV31U42A Regulatory Approval Documentation | Certifications | Download | ||
| PIC32CX-BZ6 and PIC32WM-BZ6 Application Developers Guide | User Guides | Link | ||
| MPLAB Harmony V3 Bluetooth LE Application Examples | Code Examples | Link |
