The collection of tools below includes pre-built toolchains tailored for the PIC64-HPSC and PIC64HX MPUs. All toolchains are compiled directly from the latest source code, ensuring reliability, compatibility, and up-to-date features.
Note that these tools are automatically installed when using the quick-start script found with all PIC64HPSC/HX repositories.
Explore Our PIC64-HPSC/PIC64HX Toolchain Downloads
The collection of tools below includes pre-built toolchains tailored for the PIC64-HPSC and PIC64HX MPUs. All toolchains are compiled directly from the latest source code for reliability, compatibility and up-to-date features.
Note that these tools are automatically installed when using the quick-start script found with all PIC64HPSC/HX repositories.
|
Title
|
Version Number
|
Date
|
|
|---|---|---|---|
| LLVM/GCC Toolchain (Redhat) | 1.8.0 | 31 Oct 2025 | Download |
| LLVM/GCC Toolchain (Redhat) SHA256 Revision Check File | 1.8.0 | 31 Oct 2025 | Download |
| LLVM/GCC Toolchain (Ubuntu) | 1.8.0 | 31 Oct 2025 | Download |
| LLVM/GCC Toolchain (Ubuntu) SHA256 Revision Check File | 1.8.0 | 31 Oct 2025 | Download |
RTEMS® Toolchain Downloads for the PIC64-HPSC/PIC64HX MPUs
The RTEMS Toolchain is used for compiling applications for the RTEMS Operating System and is also required when compiling the System Controller firmware. These downloads are installed automatically when using the quick-start script from the PIC64HPSC/HX RTEMS examples repository (login credentials are requied).
|
Title
|
Version Number
|
Date
|
|
|---|---|---|---|
| RTEMS Toolchain (Redhat) | 1.7.0 | 31 Oct 2025 | Download |
| RTEMS Toolchain (Redhat) SHA256 Revision Check File | 1.7.0 | 31 Oct 2025 | Download |
| RTEMS Toolchain (Ubuntu) | 1.7.0 | 31 Oct 2025 | Download |
| RTEMS Toolchain (Ubuntu) SHA256 Revision Check File | 1.7.0 | 31 Oct 2025 | Download |
Device Configurator Tool
The Device Configurator Tool (dev_cfg) is a comprehensive set of utilities for configuring, building, programming, and analyzing the power profile of PIC64HPSC/HX devices.
Its main functions include:
- project: Produces project files which are consumed by the image_builder, target and power function. Project files are used to specify boot configuration files at the board, system, and application levels.
- image_builder: Builds device binaries, including flash images and OTP memory. This covers the OTP memory section (boot config, security), system controller configuration images, and application complex configuration images.
- target: Programs device binaries onto the hardware, including OTP boot configuration, system controller flash image (for firmware upgrades), and application flash image filesystem updates. It also supports runtime configuration and device diagnostics of PIC64HPSC/HX device.
- power: Provides power profile estimation based on boot configuration files and power characterization.
The device configurator tool is automatically installed when using the quick-start script found with the PIC64HPSC/HX example repositories (login credentials are requied) and can be downloaded separately after the 2.0.0 software release.
PIC64HPSC/HX Device Configurator Tool in MPLAB® Tools for VsCode®
The device configurator tool is integrated into MPLAB Tools for Microsoft® Visual Studio Code (VS Code), allowing users to access all major functions directly within the VS Code environment. This integration streamlines the workflow for platform designers and software developers, making configuration, build, and management tasks more efficient and user friendly.
Note that the MPLAB Tools for VS Code will be available with the 2.0.0 software release.
