MATLAB^® Simulink^® With dsPIC33A Digital Signal Controllers (DSCs)

Simplifying Real-Time Control Designs With Model-Based Development

Model-Based Design (MBD) using MATLAB^®Simulink^® and the free MPLAB^® Device Blocks for Simulink provides a powerful and intuitive platform for developing real-time control applications with our dsPIC33A Digital Signal Controllers (DSCs). This integrated workflow allows you to visually model complex control algorithms and system behavior in Simulink by leveraging a rich library of peripheral blocks, including digital I/O, Analog-to Digital Converter (ADC), Pulse-Width Modulation (PWM), Quadrature Encoder Interface (QEI), I2C, SPI, UART, interrupts and resets, tailored for dsPIC33A devices.

Once the model is complete, code generation is streamlined—with a single click, the platform automatically generates, compiles and loads optimized code onto the target dsPIC33A DSC, which eliminates the need for manual, low-level programming and reduces development time.

MPLAB Device Blocks for Simulink

Create stand-alone applications from a Simulink discrete time model and with just one click, generate, compile and load the code for your application onto your target device. MPLAB Device Blocks for Simulink is a free set of user interfaces and Simulink peripheral blocks for developing complex designs based on our dsPIC33A DSCs.
