MCP344xR and MCP354xR Delta-Sigma ADCs

Economical, Precision, 16- and 24-bit Delta-Sigma ADCs

Acquire analog signals with resolutions of 16 or 24 bits from sensors and other sources using the MCP3441/2/4R and MCP3541/2/4R family of Analog-to-Digital Converters (ADCs). These economical delta-sigma ADCs feature low noise and high accuracy at sampling rates as high as 9.6 ksps.

Innovation
Products
Building Automation

Key Features

  • 16-bit resolution for MCP3441/2/4R and 24-bit for MCP3541/2/4R
  • One, two or four differential inputs (two, four or eight single-ended inputs)
  • 9.6 ksps maximum sampling rate
  • Internal 2.4V voltage reference
  • 100 nVRMS input noise (AV = 16, 3.125 sps)
