3506-most150-repeater
3506-most150-repeater

Part Number: B10322

MOST150 REPEATER


  • Two MOST150 oPHY (optical physical) layer-compliant interfaces at both main and extension sides
  • Automotive-compliant power supply
  • Low power consumption in sleep mode (< 30 µA)
  • Slave wake-up support at extension side
  • Monitor-out functionality without extra FOT on extension side
  • Status indication
  • Relay-switched lock contact max. 20 V / 1 A short-circuit protected
Request Quote

Overview

V01.00.00
Hardware
Flexible MOST® Network Extension and Signal Recovery
To view this video, please click manage cookies below and accept functional cookies.
Manage Cookies

All Application Notes

Documentation

Title
Document Id
MOST150 Repeater - MOST150 Repeater Download 5bd34bca-16cc-45a6-af07-10247f9d9051
MOST150 Repeater - MOST150 Repeater Download 29ed36e2-cdd4-47d1-ae16-949a6aa68f98
