Overview
The MTD6501G Daughter Board is a small board with the minimum components that are necessary to operate with the MTD6501G device but it is designed to be used with the ADM00532 motherboard provided by the ADM00575 kit.
· 3-Phase BLDC Sensorless Fan connector
· The MTD6501G pin access connector
· ADM00532 (see ADM00575 Kit) compatible
3x ADM00534 (MTD6501G Daughter Board)
Cannot load image!
Documentation
Filter by Document Type
Search Documentation
|
Title
|
Document Category
|
|||
|---|---|---|---|---|
| MTD6501G Daughter Board User's Guide (ADM00534) | User Guide | Download | ||
| MTD6501G 23kHz PWM Output Daughter Board (ADM00534) Schematics | Board Design Files | Download | ||
| MTD6501G 23kHz PWM Output Daughter Board (ADM00534) Gerbers | Board Design Files | Download | ||
| MTD6501G 23kHz PWM Output Daughter Board (ADM00534) BOM | Board Design Files | Download | ||
| MTD6501C/D/G Data Sheet | Data Sheets | Download |
