| Demo |
Description |
|---|
| High-Efficiency, 48V Power Conversion Solutions |
Explore our two reference designs for 48V–12V conversion. The high-efficiency Gallium Nitride (GaN)-based design is an excellent choice for data center, industrial and E-Mobility applications while the silicon-based design offers a reliable, cost-effective solution for automotive and communications. You can compare diagrams and specs to find the right fit. |
| Isolated Bias Generator for SiC Gate Drivers |
The isolated bias generator for SiC gate driver reference design is based on the MCP14T0517 push-pull transformer driver. |
| 600–1700V High-Reliability Power Module |
This demo highlights baseless modules, an ultra-low inductance SP6LI power module, SP6HPD and SP7HPD+ driver for E-Mobility, with a focus on aviation actuation. Modules include IGBT, SiC and hybrid SiC switches, offering customization for specific requirements. |
| 5.5 kW Flying Capacitor Totem-Pole (TTP) |
This demonstrates a 5.5 kW, multi-level flying capacitor Power Factor Correction (PFC) stage that is OCP ORv3-compliant as a prototype for next-generation 12 kW AC-DC supplies. It offers high power density while fitting standard
Common Redundant Power Supply (CRPS) enclosures.
|
Hardware-Based, High-Voltage Auxiliary E-Fuse
Board
|
This demo showcases an advanced Electronic Fuse (E-Fuse) solution for Electric Vehicles (EVs) and Hybrid Electric Vehicles (HEVs) that utilizes our 700V and 1200V mSiC® technology. This solution features a Time-Current Characteristic (TCC) curve for seamless integration into automotive and industrial applications like DC Solid-State Circuit Breakers (SSCBs). |
| 30 kW Vienna PFC Low-Voltage Demo |
Optimize your three-phase Power Factor Correction (PFC) systems with our advanced Vienna PFC reference design, which is very well-suited for Hybrid Electric Vehicle (HEV) and Electric Vehicle (EV) chargers, as well as high-power Switch-Mode Power Supply (SMPS) applications. Leveraging cutting-edge Silicon Carbide (SiC) technology, this design utilizes our mSIC® MOSFETs and Schottky Barrier Diodes (SBDs) to achieve an impressive 98.6% efficiency at a 30 kW output. |
| 3.3 kV HV-D3 Gate Driver Reference Design |
This demo showcases a gate driver for 3.3kV D3 SiC power module with 5W/channel, 100 kHz switching, optically isolated interface, DESAT/Undervoltage Lockout (UVLO) protection and 6 kV isolation. |
45W Auxiliary Power Supply for 800V Traction
Inverters
|
This inverter offers a high-voltage auxiliary power supply that converts DC to low-voltage outputs for traction inverter control circuits, fans and sensors. The inverter is optimized for reliability across a wide input range. |
| Half-Bridge Board With Power Motherboard |
The Half-Bridge Board (HBB) uses our mSiC® MOSFETs and is a versatile platform for designing SiC discretes into power electronics. It can be used with a Double Pulse Test (DPT) board to determine switching losses in SiC, Si and IGBT devices. |
Silicon Power Switching and High-Frequency RF
MOSFET Portfolio
|
This demo features discrete devices including diodes, IGBTs, MOSFETs and high-frequency Vertical Double-Diffused Metal-Oxide-Semiconductor (VDMOS) for DC-DC/AC-DC converters, Power Factor Corrections (PFCs), solar, Switched-Mode Power Supply (SMPS), battery charging, welding, motor control and RF applications (80V–1200V, 2–175 MHz). |
| 600–1700V High-Reliability Power Module |
This demo highlights baseless modules, an ultra-low-inductance SP6LI power module, SP6HPD and SP7HPD+ driver for E-Mobility, with a focus on aviation actuation. Modules include IGBT, SiC and hybrid SiC switches, offering customization for specific requirements. |
| Space Power Solutions |
This active demo with Space DC-DC power converter and external EMI filter demonstrates the capabilities of the converter (SA50) and EMI filter (SF100). The demo shows waveforms for min load, normal load, transient load and turn-on response for series and parallel configurations of the converter. |
| Electromechanical Power Relays |
Designed for harsh environments across transportation, space, military, aviation and downhole drilling, our portfolio of power relays includes space-grade relays, QOL relays and custom relays. Learn more about our power relay offering and get a view of the assembly process. |
| Space-Grade Brushless DC Motor Controller |
This demo showcases the LX7720MLF Evaluation Board with 24V half bridges formed by eight 150V JANSR2N7589U3 radiation-hardened (rad-hard) MOSFETs to drive a two-winding bipolar stepper motor. Applications include motor control and isolated/non-isolated DC-DC converters for satellites, deep-space probes and nuclear facilities.. |
| High-Reliability Motor Control Solutions |
This static demo in a wedge format showcases our high-reliability motor control solutions that include control (FPGA/MCU), communication (CAN/Ethernet), data acquisition (LX4580), power (MOSFETs, HPDs, PMICs) and protection (TVS) components. |
11 kW, Three-Phase PFC Demonstration
Application
|
The 11 kW, three-phase PFC demo is a modular, high-power platform showcasing dsPIC33 Digital Signal Controllers (DSCs) with SiC FETs for efficient, three-phase AC-DC conversion. Designed for automotive on-board chargers, it also fits industrial and telecom power applications and supports rapid prototyping via plug-in control modules and CAN-based PC control. |
