Microchip Technology Inc

ATmXT224T

In Production

The mXT224T uses the latest capacitive touch technologies that Microchip has designed for the highest-performance smart phones. With a revolutionary adaptive-sensing architecture that features both mutual- and self-capacitance, it enables the highest performance with the industry???s lowest power consumption.

With 224 nodes, the mXT224T touchscreen controller supports 1.0mm passive stylus, thick glove touch, moisture robustness, and superior noise immunity.


    Parameter Name
    Value
    Interface Type
    I2C
    Max Screen Size (Inch)
    4.5
    Operating Voltage range (Vcc)
    3.3 to 3.3
    Touch Response
    >250 Hz
    Automotive Qualified
    Temperature Range (degC)
    -40 to 85
    Max Nodes Supported
    224
