Microchip Technology Inc

ATmXT1664S

In Production

The Atmel® maXTouch® mXT1664S capacitive touchscreen controller brings the S Series architecture to large touchscreen devices. The mXT1664S benefits from the powerful 32-bit AVR® core and, as a result of the S Series architecture, it has the industry's highest signal-to-noise ratio (SNR), providing unrivalled touch performance. As with the other devices in the S Series, the mXT1664S includes:

  • Our thinner sensors, which enable the thinnest touchscreen stacks with the noisiest displays.
  • maXCharger™ Technology, which ensures flawless operation with any charger.

The mXT1664S delivers industry-leading performance in terms of narrow stylus operation, touch responsiveness and low power consumption. With 1,664 nodes, the device can deliver high-precision performance on tablets and notebooks, enabling designers to reach Windows 8 certification.


    Parameter Name
    Value
    Interface Type
    I2C / USB
    Max Screen Size (Inch)
    12.3
    Operating Voltage range (Vcc)
    3.3 to 3.47
    Touch Response
    >200 Hz
    Automotive Qualified
    Yes
    Temperature Range (degC)
    -40 to 85
    Number of Touches
    10
    Max Nodes Supported
    1664
