Microchip Technology Inc

ATF16V8B

In Production

250 gate, Standard power, Vcc 5V, Green package, Up to 16 Inputs, 8 I/Os, electrically erasable PLD


    Parameter Name
    Value
    Power Options
    STANDARD
    Operating Voltage range (V)
    4.5 to 5.5
    Inputs and I/O Pins
    18
    Registers
    8
    Macrocells
    8
    tPD Min
    10
    Max Clock Freq
    83
    Temp# Range (deg C)
    -40 to 85
